TE Activity: Stack It Up!
Contributed by: Integrated Teaching and Learning Program, College of Engineering, University of Colorado at Boulder
Summary |
Engineering Connection |
| Before the first stone is moved, engineers design structures by exploring a variety of design solutions, making drawings, building models, using mathematics and estimating material requirements. To build any huge structure an engineer asks and finds the answers to questions such as: What is the purpose of the structure? What will be its size and shape? How will the structure support itself? What type of material(s) should be used? How much material is needed? Where is a good location to build this structure? |
Contents
| ||||||||||||||||||||||||||||||||||
| Grade Level: 4 (3-5) | Group Size: 2 |
| Time Required: 50 minutes |
Activity Dependency  :None |
Expendable Cost Per Group
:
US$ .05 |
|
| Keywords: approximation, area, design, engineer, estimate, math, plan, pyramid, scaling, simple machine, volume | |
| Reviews: Read Reviews | Be the First to Write a Review | |
Related Curriculum
:
Pre-Req Knowledge (Return to Contents)
Multiplication, division, using a ruler, graph paper, and the concept of proportional scaling. General knowledge of pyramids. Familiarity with the six simple machines introduced in Lesson 1 of this unit.
Learning Objectives (Return to Contents)
After this activity, students should be able to:
- Understand that engineers always make a plan before building, and that plan is called a design.
- Understand that engineers analyze a project before attempting to construct anything.
- Understand that engineers must meet the constraints of a project, such as how far stones must be moved, how large stones can be and still be able to be moved to the pyramid construction site, etc.
Materials List (Return to Contents)
Each group needs:
- A calculator
- Pencils and erasers
- A scaled ruler
- Graph paper
- Stack It Up! Math Worksheet
Introduction/Motivation (Return to Contents)
Imagine you are the chief engineers on a pyramid construction project in ancient times. You have been given specific dimension guidelines for the pyramid: its length and width (both 120 meters) and height (72 meters). All the other decisions involving the pyramid construction are left to you. As engineers, it is your task to ensure that the new pyramid is built solidly, efficiently, and completed on time, while also making sure that it is beautiful and lasts a long time. Developing a good plan — a design — helps you meet all of these goals.
 |
Engineers need to make sure that they develop a good design that is durable and that takes environmental conditions into account, such as topography and weather. However, even if you succeed in these areas, your leader will be unhappy if the project costs more than expected. Additional time and money would be wasted if you cut more rock from the quarry than needed for the pyramid or if you do not cut enough and must go back to the quarry to get more stones to finish the job. So, as engineers, you must make accurate estimations. Either overestimating or underestimating the amount of materials is unacceptable.
Engineers must also be accurate in the timeline they give to the leader. If the project takes longer than estimated, your leader will be impatient and disappointed. On the other hand, if you finish ahead of schedule, instead of being pleased that you finished so quickly, your leader might be angry about not having enough time to plan a celebration for the unveiling of the pyramid. Given such an important job, you must draw on your engineering skills to build a pyramid that pleases your leader based on how magnificent it looks, sturdy it is, quickly it is built, and efficiently it is constructed.
Vocabulary/Definitions (Return to Contents)
| Approximation: | Simplifying a problem to get an answer that is close but not exact. |
| Area: | The amount of surface space (in two dimensions) that an object takes up. |
| Design: | (verb) To plan out in systematic, often graphic form. To create for a particular purpose or effect. Design a building. (noun) A well thought-out plan. |
| Estimate: | A rough or approximate calculation. |
| Plan: | (noun) A method worked out before hand for the accomplishment of an objective. |
| Scaling: | Drawing an item smaller or larger than actual size, but keeping the same relative proportions. For example, perhaps 1 cm represents 1 meter. |
| Topography: | The surface features of a place or region. |
| Volume: | The amount of space (in all three dimensions) that an object takes up. |
Procedure (Return to Contents)
Before the Activity
- Gather materials and make copies of the Stack It Up! Math Worksheet.
With the Students
- Divide the class into engineering project teams of two students each.
- Explain the concept of scaling.
- Hand out the worksheets and graph paper.
- Explain that each team's job is to use the worksheet to make detailed plans for their pyramid, and use the graph paper to make a scaled drawing of their pyramid design.
 |
- Observe the students as they work through the worksheet calculations, helping as needed.
- Help students decide on a scale that fits the pyramid drawing optimally on the graph paper.
- Now that the students have been introduced to the design and analysis process that all engineers use to some extent, conclude the activity with a classroom brainstorming session (see the Assessment section for details). Ask the students to share with the class all the important design questions, constraints, or other topics to consider, investigate, analyze and test before building a pyramid — or any structure.
Attachments (Return to Contents)
- Stack It Up! Math Worksheet (doc)
- Stack It Up! Math Worksheet (pdf)
- Stack It Up! Math Worksheet Answers (doc)
- Stack It Up! Math Worksheet Answers (pdf)
Troubleshooting Tips (Return to Contents)
Before students begin to write on the graph paper, make sure they have decided on a scale that fits the pyramid drawing optimally on the graph paper.
Some students may need a reminder explanation about the units for area (m2) and volume (m3).
For an ELL focus, use multiple sensory associations, visuals, etc.
Assessment (Return to Contents)
Pre-Activity Assessment
Brainstorming: In small groups, have students engage in open discussion to generate a number of possible ideas about how the pyramids were built. Have them think about the physical processes involved (cutting and moving stone) and the mental processes (design and planning). Have one person record all proposed ideas on the classroom board. Encourage wild ideas and discourage criticism of ideas. Remind students that no idea or suggestion is "silly." All ideas should be respectfully heard.
Roundtable: Form teams of three to five students each. Ask the class how the pyramids might have been built. Have students on each team make a list, each one writing an answer and passing the paper on to the next person. Review the six types of simple machines (wedge, wheel and axle, lever, inclined plane, screw, and pulley) and ask if using any of these approaches might be helpful in the difficult work required to construct a pyramid. After students write down a few more ideas, have the teams share their responses with the class.
Activity Embedded Assessment
Worksheet: Have the students provide answers and complete the calculations on the Stack It Up! Math Worksheet. Review students' worksheet progress to gauge their mastery of the subject.
 |
Post-Activity Assessment
Closing Brainstorming: Now that students have been introduced to the design and analysis process that all engineers use to some extent, ask the students share with the class all the important design questions, constraints, or other topics to consider, investigate, analyze and test before building a pyramid — or any structure (houses, bridges, skyscrapers). Encourage wild ideas and discourage criticism of ideas. All ideas should be respectfully heard.
Activity Extensions (Return to Contents)
For a class project or individual assignment, have students examine more closely the geology of Egypt and how one builds on a desert of sand.
Activity Scaling (Return to Contents)
- To increase the difficulty, use block dimensions that are harder to calculate, such as a block sized 5.0m x 2.2m x 3.7m.
References (Return to Contents)
Dictionary.com. Lexico Publishing Group, LLC. Accessed January 11, 2006. (Source of some vocabulary definitions, with some adaptation) http://www.dictionary.com
Contributors
Gregory Ramsey, Glen Sirakavit, Lawrence E. Carlson, Jacquelyn Sullivan, Malinda Schaefer Zarske, Denise Carlson, with design input from the students in the spring 2005 K-12 Engineering Outreach Corps course.Copyright
