Lesson: The Cloning of Cells
Contributed by: Integrated Teaching and Learning Program, College of Engineering, University of Colorado at Boulder
 |
Figure 1. Mouse embryonic stem cells stained with a fluorescent marker. click for copyright |
Summary |
Engineering Connection Category 1. Relating science concept to engineering |
Contents
|
| Grade Level: 7 (6-8) | Lesson #: 3 of 3 |
Lesson Dependency  :None |
|
| Keywords: stem cell, fluorescent dye, bioengineering, cells, cancer, tissue, mitosis | |
| Reviews: Read Reviews | Be the First to Write a Review | |
Related Curriculum
| subject areas |
Biology |
| curricular units |
Cells |
| activities |
Glowing Flowers |
Educational Standards :
- Colorado Science
- International Technology Education Association-ITEA STL Standards Technology
Pre-Req Knowledge (Return to Contents)
Students should have knowledge of the parts of a cell and cell function.
Learning Objectives (Return to Contents)
After this lesson, students should be able to:
- Define stem cells.
- List several applications of stem cells research.
- Describe engineering designs that are advancing stem cell research.
Introduction/Motivation (Return to Contents)
We have cells throughout our entire body.... thousands upon thousands of cells. Who can tell me what cells do? They keep us alive! They are the foundation of life and without them; there would be no life on Earth. We have so many cells throughout our bodies that it is hard to count them all. Does anyone have any guesses on how many cells are in an average human body? About 100 trillion! They are typically very small, around 10 μm - that's smaller than the diameter of a human hair. (Fun Fact: The largest known single cell is actually quite large - an ostrich egg!)
We have about 210 different types of cells in our bodies, with each having a different function, or job, to keep us alive and healthy. Blood and immune system cells, including red and white blood cells, keep blood running through our body to our organs and help fight off illness. Brain cells, including neurons, carry electrical signals through our brains, transmitting information and instructions. When we are in class, our brain cells are working to store new information that is being learned, while at the same time, also carrying information to different parts of the brain to tell our bodies to keep our hearts beating and our lungs breathing so we stay alive.
Since cells are so important, what can we do if our cells get "sick"? Well, among trying to return the cells to a healthy state, some people believe stem cells are the answer to treating life-threatening diseases or medical conditions. While controversial (i.e., meaning people disagree about it), stem cell research is a popular research subject right now as well as a hot platform for politics!
Lesson Background & Concepts for Teachers (Return to Contents)
Cancer, one of the main causes of death in America, is a disease where one type of cell divides and replicates rapidly within tissue that has a specific type of cell needed for proper body function. What do you imagine might happen if "sick" blood cells began dividing rapidly in our brains and invading the space that neurons usually occupy? How would our bodies know to keep our hearts beating and lungs breathing if neurons began to be replaced by blood cells? There are currently a number of treatment options for cancer, including surgery and chemotherapy. The goal of surgery is to entirely remove the cancer cells. Unfortunately, this is not always possible, and much depends on where the cancer is actually located. Chemotherapy, on the other hand, is not the removal of the "sick" cells, but the interference with cell division to destroy cell life and additional cell growth. However, the chemotherapy process targets all rapidly dividing cells, not just cancer cells, which can then affect other "healthy" cells in the body, such as hair and intestinal cells, causing a person to get sick from the treatment procedure itself.
Another treatment option that is being researched involves the use of a certain type of cell called stem cells. Does anyone know what a stem cell is? There are two types of stem cells: embryonic stem cells, found in a developing human embryo, and adult stem cells, found in umbilical cord blood and bone marrow. Stem cells have the ability to replicate themselves by mitosis and be grown and differentiated into the many cells in our bodies, including different types of muscle and brain cells. In adult humans, stem cells work to replace damaged tissue but are also involved in normal regeneration of cells, such as skin and blood. Embryonic stem cells can actually regenerate into more than 200 types of adult cells, given the right environment and stimulation for that cell type. The applications of stem cells for medical therapies include treatments of cancer and spinal cord injuries, among others.
 |
Figure 2. Stem cells collected from human bone marrow. click for copyright |
Researching how stem cells behave in our bodies is crucial before stem cell treatments can be used. Engineers play a big part in this research. One engineering design currently being researched is the development of a three-dimensional microscopic housing structure that would allow scientists to look at stem cell behavior from every direction. This is very important since stem cells are indeed affected from all directions. For example, if we were looking for an apartment in a multi-story building and we were told that the noise level of the next-door neighbors was very low, we would be very disappointed if we moved in and found out that the residents below and above us were extremely loud. It is clear to us, then, that we did not have all of the information needed before we chose that apartment. Without an engineered technology to analyze stem cells from every direction, scientists would not have all the information they need to develop safe and effective medical treatments.
Another key role of engineers in stem cell research is developing ways to track stem cell behavior once injected into an organism. Chemical engineers helped to develop different fluorescent proteins that act as markers based on naturally occurring fluorescent proteins in jellyfish. These green fluorescent proteins (GFPs) can be linked to naturally-occurring proteins and injected into an organism, such as a mouse. The mouse then produces fluorescent green, protein-linked cells, including stem cells, which can be extracted and injected into another mouse to see where the new fluorescing stem cells travel (see Figure 3). Shining a blue light onto the mouse will cause the GFPs to glow brightly and easily be seen. The injected stem cells with GFPs can then be easily traced to see if they move toward a certain part of the body and what type of cells they differentiate into within the animal.
The Controversy
Stem cells are currently a controversial topic because the use of embryonic stem cells involves either the destruction of a human embryo or therapeutic cloning of cells, which is the basis of cloning animals and possibly even humans. Research is being done to find a way to generate embryonic stem cell lines without the destruction of embryos. There is little controversy over the use of adult stem cells found in adult tissues. In fact, adult stem cells have been used for years to treat leukemia and bone cancers through bone marrow transplants.
 |
Figure 3. Mice born with a green fluorescent protein (GFP) stain. click for copyright |
Arguments against embryonic stem cell research include concerns around reproductive cloning and challenges to personal or religious beliefs. Arguments for embryonic stem cell research include insistence that stem cells are necessary for the advancement of medical science and may save lives. Proponents of stem cell research position that the only embryos used for research are those that would be discarded anyway. The social and ethical challenges behind stem cell research have had a large impact on government funding and regulations. It is a topic that seems to be growing in debate.
Vocabulary/Definitions (Return to Contents)
| Stem cell: | A cell that is able to replace itself and differentiate into another cell type in the body. |
| Fluorescence: | Bright light shining from an object as a result of high energy photons (light), such as Ultraviolet Light or X-rays. |
| GFP: | Green Fluorescent Protein; a dye created by engineers to simulate naturally occurring fluorescence in jellyfish. |
Associated Activities (Return to Contents)
- Glowing Flowers - Students learn about engineering design of green fluorescent proteins (GFPs) and their use in stem cell research. Girls and boys use a fluorescent dye mixed in water to follow the movement of water through a plant and extend their knowledge to GFP-linked cells moving through an animal organism.
Lesson Closure (Return to Contents)
Stem cells are cells that are able to replace themselves and be grown and differentiated into the various cell types in our bodies. Stem cell research has looked at using stem cells to replace damaged tissue and regenerate cells like skin and blood. The applications of stem cells for medical therapies include treatments of cancer and spinal cord injuries. Engineers are highly involved in stem cell research. They design the technologies that lead to the understanding of stem cells, their structure, and how they differentiate into other cells. Engineers also develop ways to find and track stem cells when placed into different environments. One example is the development of green fluorescent proteins (GFPs) that have been injected into mice to follow the replication and differentiation of stem cells. Can you think of other ways that engineers are involved in the medical field? (Ask students to get into groups of three and write or draw pictures of engineering applications that involve cells and medical research. Discuss these as a group.)
Assessment (Return to Contents)
Pre-Lesson Assessment
Discussion Question: Ask a discussion question to get students thinking about the upcoming lesson. After soliciting answers, explain that these questions will be answered during the lesson.
Ask the students to define cells and what they think stem cells are. Write the responses on the board. Leave the responses on the board and attempt to discuss them throughout the lesson.
Post-Introduction Assessment
Question/Answer: Ask the students questions and have them raise their hands to respond. Write their answers on the board.
- What are stem cells? (Answer: A cell that is able to replace itself and transform into another cell type in the body.)
- Why are scientists interested in learning more about stem cells? (Answer: They may have medical applications that could help treat specific diseases and injuries.)
- How do engineers make it possible for scientists to study stem cells? (Answer: They create instruments to look at the stem cells from every direction and develop specialized proteins to study stem cells in animals.)
Lesson Summary Assessment
Engineering Impacts: Engineers have to think about the broader impacts of a design when developing new systems and technologies. Have the students, in pairs or as small groups, think about the different considerations an engineer would likely think about when designing technologies for stem cell research. Some of these might include the impacts on individuals, society and the environment, as well as ethical, economic, social and political considerations.
Lesson Extension Activities (Return to Contents)
Court is in Session: Ask the class to split into two groups: one in support of stem cell research and one against it. Have each team research the controversy behind stem cell research. Ask each team to prepare an argument to bring to "court." This should include drawings on butcher paper, diagrams, facts referenced from a reliable source, pros and cons, etc. A simple debate can be performed, or each team can choose a couple of witnesses (such as an engineer and a politician, etc.) and a couple of lawyers to question the witnesses from the other team. The judge can be the teacher. Opening and closing arguments should be similar to having a debate.
References (Return to Contents)
Geijsen, Niels. Massachusetts General Hospital, National Science Foundation, Office of Legislative and Public Affairs, NSF PR 03-142 - December 10, 2003, accessed October 3, 2008. <http://www.nsf.gov/od/lpa/news/03/pr03142_images.htm>
U.S. National Institutes of Health, National Institute of Child Health and Human Development, July 18, 2006, accessed October 3, 2008. <http://www.nichd.nih.gov/news/releases/green_brown_mice.cfm>
U.S. National Institutes of Health, National Institute on Aging, "Chapter 5: The Future of Aging," January 31, 2008, accessed October 3, 2008. <http://www.nia.nih.gov/HealthInformation/Publications/AgingUndertheMicroscope/chapter05.htm>
