Lesson: Sound Extenders
Contributed by: Integrated Teaching and Learning Program, College of Engineering, University of Colorado at Boulder
 |
Figure 1. Alexander Graham Bell click for copyright |
Summary |
Engineering Connection Category 1. Relating science concept to engineering |
Contents
|
| Grade Level: 4 (3-5) | Lesson #: 2 of 3 |
Lesson Dependency  :None |
|
| Keywords: Alexander Graham Bell, telephone, communication, sound, sound waves | |
| Reviews: Read Reviews | Be the First to Write a Review | |
Related Curriculum
| subject areas |
Science and Technology |
| curricular units |
Sound |
| activities |
String Telephones |
Educational Standards :
- Colorado Science
- International Technology Education Association-ITEA STL Standards Technology
Pre-Req Knowledge (Return to Contents)
Students should be familiar with sound being described as a wave. This lesson would work well accompanying a science unit on sound or waves.
Learning Objectives (Return to Contents)
After this lesson, students should be able to:
- Describe sound as a wave that diminishes in strength as it travels.
- Name the engineer that invented the telephone.
- List an impact of the telephone on people or society.
Introduction/Motivation (Return to Contents)
Note: a slinky and an approximate 5 foot long, small-diameter PVC pipe (or other kind of rod) is required for this Introduction.
Can you hear me now? (Students should answer affirmatively.) If we were outside on opposite sides of the playground, would you be able to hear me? (Answer: no) Why is that? (Expect various answers.) Sound waves tend to lose their power as they travel. Let's take a look at a model.
(Pick up a metal slinky and place it over the 5 ft. rod. Have a volunteer hold onto the other end of rod. Stretch the slinky across the rod and ask volunteer to firmly hold their end of the slinky. Push abruptly on the slinky from your end to create a wave that moves from side to side.)
Notice how the wave moves across the slinky. This is how a sound wave moves through air and solids. Do you see how the wave starts out strong and tends to die out on the other end? The wave is given energy at the beginning, but then that energy is used up as the wave travels across the slinky. Let's see it again. (Demonstrate the wave again.) The slinky steals the energy that is given to the wave.
Now imagine that on the other end of the slinky is your ear. Also imagine that my mouth is on my end. As I talk, I produce waves in the air that travel to your ear. What does the slinky represent? (Answer: the air) So that is how sound travels: from my mouth to your ear in the form of a wave that decreases in strength with distance.
 |
Figure 2. Telephone lines stretch across our nation and world. click for copyright |
Do you think it would be helpful to be able to speak with someone who is far away from you, maybe in another city? You think yes? Well, you are not the only ones. What is the invention that allows us to do this? (Answer: The telephone; ask if students know who invented it.)
Note: Consider printing the following paragraph and reading as a class.
Alexander Graham Bell (1847 - 1922) was a communications engineer and inventor who, like his family, had a lifelong fascination with sound. Both his father and grandfather taught people how to speak more clearly, including the deaf. Bell's mother was herself deaf. While others would speak to her through an ear tube (a cone-shaped device that makes sounds louder), young Alexander decided to speak in a low voice at her forehead. Alexander devoted much of his life to helping people hear and be heard. He is most famous for allowing people to hear each other over the telephone, which he invented in 1876.
How do you think Alexander's mother could hear him? (Answer: She could feel the vibrations of his voice.)
The name of this lesson is "Sound Extenders." Where do you think this name comes from? (Answer: The telephone "extends" sound over great distances.) What are some other "sound extenders?" (Answers: cell phones, live television, video phones, loudspeakers) The people who create and make available these "sound extenders" are known as communications engineers. They notice that sound dies down with distance, just as we notice it, and use their creativity to allow sound to travel greater distances. Alexander Graham Bell was one of the first communications engineers.
Lesson Background & Concepts for Teachers (Return to Contents)
A sound wave is often thought of as a pulse of energy. The wave travels by pushing on the medium it is moving through — air, liquid or solid. With each push on the medium, that portion of the medium pushes on the next portion and so on, thus creating the chain of pressures that is the sound wave. It takes energy to create a sound wave — to create movement that is opposed by friction. It is important to note that the energy is not destroyed as the wave travels along; rather, it is turned into a tiny amount of heat (this is the same phenomenon of rubbing your hands together: overcoming friction creates heat).
 |
Figure 3. The cell phone is everywhere. click for copyright |
The less energy a sound wave has, the less loud it is when it strikes our ear. Therefore a wave that has been traveling a great distance, though loud to the person nearby, could be quite soft to the person it finally reaches. Out of this characteristic of sound, and other limitations, the need for a telephone was perhaps recognized. A telephone does not record sounds and then replay them at the other end of the line. Rather, a telephone allows sound waves to be "extended" over a greater distance by translating them into a wave on an electric current. This translation is reversed at the other end of the line to create a wave through the air which we are able to hear.
Vocabulary/Definitions (Return to Contents)
| Acoustics: | The study of sound; the characteristics of sound in an environment. |
| Alexander Graham Bell: | Inventor of the telephone. |
| Communications Engineering: | The branch of engineering having to do with developing and maintaining technology used for communication, such as telephones. |
Associated Activities (Return to Contents)
- String Telephones - Students investigate how sound travels through both string and air by developing a string telephone.
Lesson Closure (Return to Contents)
Why is the telephone a useful engineering achievement? Well, we know that the sound we hear gets smaller with distance, so we need things like telephones (or other engineered devices that "extend sound") to talk to each other from far away. How have telephones and cell phones made life easier? (Answers will vary, but may include: communications with family, friends and businesses far away.) Why do you think engineers like Alexander Graham Bell invent the things they do? Alexander Graham Bell wanted to help people hear each other and be heard. Many engineers design things that help other people. Engineers have improved Bell's original telephone over the years by making the sound clearer and the telephones portable.
Assessment (Return to Contents)
Pre-Lesson Assessment
Poll: Before the lesson, ask all students:
- Who here uses a telephone? How many times a day? Week?
Write on board how many people do and how many people do not.
Post-Introduction Assessment
Brainstorming: As a class, have the students engage in open discussion. Remind students that in brainstorming, no idea or suggestion is "silly." All ideas should be respectfully heard. Encourage wild ideas and discourage criticism of ideas. Have them raise their hands to respond. Ask students
- What are cell phones useful for?
Lesson Summary Assessment
Engineering Impacts: Have students think about life before the telephone or cell phone. Ask them how the telephone has made a difference in people's lives. How have telephones helped families? Businesses? Schools? What are two limitations that engineers might think about in their design of telephones? Hint: Materials, weight, size, etc. How have these limitations affected how people use telephones?
Lesson Extension Activities (Return to Contents)
As a child, young Alexander Graham Bell displayed a natural curiosity about his world. Have students research Alexander Graham Bell. What was the path that led him to become an inventor? Have the students write a story about Alexander set in modern times. What might he be curious about? What might he invent?
References (Return to Contents)
Gralnick, Jeff. America.gov, eJournal USA, "The Next New Thing is Here," March 2006, accessed July 25, 2008. http://usinfo.state.gov/journals/itgic/0306/ijge/gralnick.htm
National Institutes of Health, Department of Health and Human Services, National Institute of Environmental Health Sciences, NIEHS Kids' Pages, "Let's Go to a Party Puzzles!" January 22, 2008, accessed July 24, 2008. http://www.niehs.nih.gov/kids/rdparty.htm
U.S. Department of the Interior, National Park Service, Petrified Forest, "Historic Route 66," January 26, 2007, accessed July 24, 2008. http://www.nps.gov/pefo/historyculture/historic-route-66.htm
