Hands-on Activity: Microplastic Extraction of Exfoliating Beads from Cleansers

Contributed by: SHIFTED RET Program, University of Kansas Lawrence and Greenbush

A close-up photograph shows various types, colors and shapes of small plastic particles.
The tiny plastic microbeads found in exfoliating cleansers and gels end up as water pollution. How can we filter them out of the water?
copyright
Copyright © 2012 image by 5Gyres, courtesy of Oregon State University, Flickr CC BY-SA 2.0 https://www.flickr.com/photos/oregonstateuniversity/21282786668

Summary

After watching a short online video that recaps the enormous scale of accumulating plastic waste in our oceans, student teams are challenged to devise a method to remove the most plastic microbeads from a provided commercial personal care product—such as a facial cleanser or body wash. They brainstorm filtering methods ideas and design their own specific procedures that use teacher-provided supplies (coffee filters, funnels, plastic syringes, vinyl tubing, water, plastic bags) to extract the microplastics as efficiently as possible. The R&D student teams compare the final masses of their extracted microbeads to see which filter solutions worked best. Students suggest possible future improvements to their filter designs. A student worksheet is provided.
This engineering curriculum meets Next Generation Science Standards (NGSS).

Engineering Connection

Keeping water resources free of plastic is a challenge since microplastics are not soluble nor magnetic, and vary in size, material composition, and decomposition stage. Because plastic pollution is a growing issue, engineers are designing new technologies to remove microplastics from drinking water and the natural environment. In this activity, students get a taste of this clean-up challenge by developing their own methods to extract microplastics from samples of commercially available facial cleansers.

Pre-Req Knowledge

It is recommended that students complete the associated lesson prior to conducting this activity.

Learning Objectives

After this activity, students should be able to:

  • Evaluate environmental impacts of personal care products.
  • Develop and test a model for an innovative and efficient water filtration system and recover contaminants/resources.

More Curriculum Like This

The Plastisphere: Plastic Migration and Its Impacts

Students learn how plastics in the human trash stream end up as microplastic particles entering the food chains via polluted water, harming animals and people. They think of ways to reuse or replace the common plastic items they discard daily. They learn how microplastics persist in the environment ...

What's Air Got to Do with It? Properties & Quality

Students use M&M® candies to create pie graphs that express their understanding of the composition of air. Next, they watch and conduct several simple experiments to develop an understanding of the properties of air (it has mass, it takes up space, it can move, it exerts pressure, it can do work). F...

Skin and the Effects of Ultraviolet Radiation

After seeing ultraviolet-sensitive beads change color and learning how they work, students learn about skin anatomy and the effects of ultraviolet radiation on human skin, pollution's damaging effect on the ozone layer that can lead to increases in skin cancer, the UV index, types of skin cancer, AB...

Introduction to Water Chemistry

Students are presented with examples of the types of problems that environmental engineers solve, specifically focusing on water quality issues. Topics include the importance of clean water, the scarcity of fresh water, tap water contamination sources, and ways environmental engineers treat contamin...

Middle School Lesson

Educational Standards

Each TeachEngineering lesson or activity is correlated to one or more K-12 science, technology, engineering or math (STEM) educational standards.

All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN), a project of D2L (www.achievementstandards.org).

In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics; within type by subtype, then by grade, etc.

  • Design, evaluate, and refine a solution for reducing the impacts of human activities on the environment and biodiversity. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Evaluate or refine a technological solution that reduces impacts of human activities on natural systems. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Summarize, represent, and interpret data on a single count or measurement variable (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Students will develop an understanding of the effects of technology on the environment. (Grades K - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Students will develop an understanding of the role of troubleshooting, research and development, invention and innovation, and experimentation in problem solving. (Grades K - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Summarize, represent, and interpret data on a single count or measurement variable. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Design, evaluate, and refine a solution for reducing the impacts of human activities on the environment and biodiversity. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Evaluate or refine a technological solution that reduces impacts of human activities on natural systems. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
Suggest an alignment not listed above

Materials List

Each group needs:

  • small whiteboard (or poster board) with markers
  • 3 coffee filters, such as from a pack 100 unbleached #4 size for $3.50 from Walmart
  • 1 funnel, such as a 4.25 inch-diameter plastic funnel for $4 from Amazon
  • 1 syringe, such as the 100-ml plastic syringe for $2 from Amazon
  • 30 cm tubing; match gauge to syringe and funnel; for example, the linked funnel’s exit tip outer diameter is .5-inch, so the .5-inch outer diameter x 3/8-inch inner diameter x 10 feet clear vinyl tubing for $8 from Amazon works well
  • 1 beaker with 30 ml of water; students may need all this water!
  • 1 wastewater container, a small plastic bag or Tupperware container works well
  • 1 tablespoon (about 1 oz) of cleanser with microplastic beads, such as Clean & Clear Deep Action Cream Cleanser for Face, Olay Fresh Effects Deep Pore Clean Plus Exfoliating Scrub, Olay Fresh Effects Bead Me Up Exfoliating Cleanser and others; often “exfoliating” or “microbeads” are mentioned on the packaging; usually ~$5-8 per tube of 5-7 ounces each; plan on about 10-12 oz per class of 30, and only one product is required for student extraction.
  • safety goggles, one pair per person
  • Microplastic Masses Worksheet, one per student

To share with the entire class:

  • technical capability to show a 3-minute online video from 5Gyres
  • tablespoons, 1 per team, for giving each team a cleanser sample for microbead extraction; same for all teams; measure empty tablespoon and provide weight to students
  • scale, to measure in milligrams or even more precisely
  • water and sink

Introduction/Motivation

Plastic pollution has been around since the plastic age began in the mid-twentieth century. Today, more and more researchers are investigating the impacts of plastics on the health of humans and other species. In addition, awareness is growing about the existence of plastic “sinks” in the ocean where large amounts of buoyant, lightweight waste accumulate. Let’s watch this video to learn more. (Play the video.)

Many commercial products contain plastic microbeads. For example, they are specifically added into some facial cleansers for the advertised purpose of the “deep exfoliating” of skin. Although they are small, the plastic microbeads that are present in facial cleansers and shower gels and even toothpaste can also contribute to these plastic ocean “gyres.” We are now realizing that these and other personal care products (PCPs) are pollution! Microplastics usually slip right through our municipal water treatment plants and find their way into rivers, lakes and oceans. So environmental engineers are developing technologies to filter microbeads from water.

Two photographs. A close-up of the label for a tube of “extra gentle daily scrub” for face and all skin types. Further, it says: Gently exfoliates with micro-fine particles to reveal radiant-looking skin. A close-up photograph shows the tip of a finger with a blob of clear gel containing a scattering of tiny round blue particles—plastic microbeads.
Many commercial products such as facial cleansers contain tiny plastic microbeads that end up contaminating the water in lakes and oceans.
copyright
Copyright © (left) 2018 Denise W. Carlson, ITL Program, College of Engineering and Applied Science, University of Colorado Boulder; 2015 Minnesota Pollution Control Agency, Flickr CC BY-SA 2.0 https://www.flickr.com/photos/mpcaphotos/22208966814/

Your challenge today is to work as environmental engineers to develop a method to remove as many plastic microbeads as possible from one tablespoon of cleanser. After extraction, you will weigh the beads. This is similar to how scientists, engineers and inventors conduct “research and development” (R&D) work in order to come up with new solutions to problems. Remember, your team’s goal is to design a filter system to remove the most beads from a sample of a commercial cleanser, which is the first step to creating a good way to clean the environment of microplastics pollution.

Vocabulary/Definitions

gyre: A system of circular ocean currents formed by global wind patterns and forces created by Earth's rotation.

microplastics: Small plastic particles in the environment. NOAA defines microplastics as less than 5 mm in diameter. May be composed of various plastic types. May be originally small microbeads or result from the breakdown of bigger plastic pieces. May be from sources such as personal care products, clothing and industrial processes.

Procedure

Background

Microplastics are particles of various types of plastic classified by the U.S. National Oceanic and Atmospheric Administration as being less than 5 mm in diameter. These might be broken-down pieces of larger plastic items or they manufactured microbeads originating from beauty products intended to clean skin. Because they are found in various shapes and sizes, are not predictably biodegraded, and are non-magnetic, microplastic are difficult to filter out and can easily pass through wastewater treatment plants and into waterways. Microplastics are increasingly found in aquatic food webs, prompting attempts around the world to eliminate plastic microbeads from consumer products and research better ways to remove these pollutants from the environment.

Before the Activity

  • Gather materials and make copies of the Microplastic Masses Worksheet.
  • Using the scale, measure and record the empty weight of one tablespoon. You will provide this weight to students so they can determine the initial masses of their samples.
  • Prepare tablespoon samples of the commercial cleanser, one per group. Set aside.
  • Organize the rest of the materials, one pile per group.
  • Be ready to show the class a three-minute video from 5Gyres, Plastic Pollution in the World’s Oceans from Chris Jones at https://player.vimeo.com/video/113359330.
  • Have the commercial cleanser product handy for informal and general examination during team brainstorming.

With the Students: Designing a Filter for Microplastics

  1. Present the Introduction/Motivation content to the class, including showing the online video and explaining the engineering challenge.
  2. Organize the class into groups of two to four students each.
  3. Have teams each observe and touch a sample of a cleanser that contain small beads.
  4. Conduct the pre-activity assessment as described in the Assessment section. As an outcome of this team brainstorming, each team generates a general plan—in the form of a diagram or sketch—of a possible way they could extract microbeads from a personal care product.

With the Students: Developing a Successful Filter for Microplastics

  1. Give each group 1 tablespoon of cleanser. Inform the groups that they will each only receive one tablespoon, so they need to take care to avoid spilling it or using it without planning ahead.
  2. Distribute the worksheet and tell students the empty tablespoon weight. Have students place the tablespoon with cleanser sample on the scale, and then calculate the initial mass of the sample.
  3. Direct students to collect their teams’ materials and set them on their tables. Then have students talk within their groups about what they could do with the provided materials to accomplish the challenge. Encourage all group members to contribute to the discussions.
  4. Then have students alter their earlier pre-activity brainstorming filter diagrams/plans to figure out how they could set up the given materials to extract the plastic beads from the cleanser sample. Make a final design plan on the worksheet in the form of a diagram or sketch with materials indicated.
  5. Require each group to show its final filter diagram to the teacher before constructing it. Alert them to be prepared to answer clarifying questions to explain the filter logic. The teacher does not provide advice but just asks students to explain the reasoning behind the design with prompts such as: Explain why you have set up the filter this way.
  6. After approval, have teams set up their filter systems and begin extracting microbeads. Remind them of the goal: To extract as many clean beads as possible.
  7. Direct the groups to set aside all their extracted beads on coffee filters to dry undisturbed. Make sure students identify the coffee filters with team/student names.
  8. The following class period, after the beads and filter are completely dry, determine which group executed the most effective filtration system by weighing the dry extracted beads for each team.
  9. Lead a short discussion to share, compare and evaluate results across all teams.
  10. Give students time to add to their worksheets their redesign/improvement ideas in the form of notes and revisions to the original team diagram/sketch to show any changes they would make after observing other groups systems and microplastics extraction results.
  11. As a post-activity assessment, have students answer the worksheet reflection questions, as described in the Assessment section.

Attachments

Safety Issues

Safety goggles are required due to the hazards of soap being used in syringes.

Investigating Questions

How can we filter out microplastics from a liquid waste stream? (Answer: Use a material like a coffee filter that permits water to pass through but not particulates.)

Assessment

Pre-Activity Assessment

Idea Generation: Have students brainstorm and talk in their teams to hypothesize ways to remove (extract) the microplastics in the commercial cleanser product for further observation. Suggest that students carefully observe and touch the cleanser. Direct them to write down their ideas and plans in the form of diagrams and sketches on a group whiteboard or poster board. Expect them to end up with a general agreed-upon plan/procedure/method for extracting microbeads from the cleanser.

Activity Embedded Assessment

Design, Build and Test: As teams are working to develop successful microplastic filters, watch that students work together in groups to design, construct and use the filters, aiming for every student to have the opportunity to contribute to the design-build-test process.

Post-Activity Assessment

Group/Self Evaluations: Conclude the activity by having students individually provide written answers to the reflection questions on the Microplastic Masses Worksheet.

  1. How did your team do?
  2. Why did you take the steps you did with your team?
  3. What proportion of your initial cleanser sample was extracted as beads?
  4. Provide details about why your method was or was not effective.
  5. What steps would you take next time to improve the method/procedure?
  6. How effective were you as a productive group member?

Activity Extensions

Using samples from local water sources, develop and implement ways to extract and quantify the presence of microplastics.

Activity Scaling

  • For lower grades, provide less emphasis on real-world applications. Shift the focus from cleaning up plastics in the ocean to designing a small filter for their bathroom sinks to capture microbeads at that location.
  • For higher grades, provide more connection to real-world ecological and environmental engineering applications. Challenge students to brainstorm large-scale microplastics filters that could be effective at cleaning plastics from ocean gyres.

Additional Multimedia Support

During the Introduction/Motivation section, show students a three-minute video from 5Gyres, Plastic Pollution in the World’s Oceans from Chris Jones at https://player.vimeo.com/video/113359330.
