SummaryStudents investigate how sound travels through string and air. First, they analyze the sound waves with a paper cup attached to a string. Then, they combine the string and cup with a partner to model a string telephone. Finally, they are given a design challenge to redesign the string telephone for distance. They think about their model as it compares a modern telephone and the impact the invention of the telephone has had on society.
Engineers systematically analyze materials and processes in order to create things for the benefit of humanity and our world. Communications engineers are particularly focused on sound and creating technology to transmit sound long distances with little loss in clarity.
Students should be familiar with sound being described as a wave. This activity works well accompanying a science unit on sound or waves.
After this activity, students should be able to:
- Describe how sound travels through different media.
- Model and analyze a string telephone.
- Recognize that technology has helped people communicate over long distances.
More Curriculum Like This
Students are introduced to communications engineers as people who enable long-range communication. In a demonstration, students discuss the tendency of sound to diminish with distance and model this phenomenon using a slinky.
Students are introduced to sound energy concepts and how engineers use sound energy. Through hands-on activities and demonstrations, students examine how we know sound exists by listening to and seeing sound waves
Students learn about the types of seismic waves produced by earthquakes and how they move the Earth. Students learn how engineers build shake tables that simulate the ground motions of the Earth caused by seismic waves in order to test the seismic performance of buildings.
Students learn about glaucoma—its causes, how it affects individuals and how biomedical engineers can identify factors that trigger or cause this eye disease, specifically the increase of pressure in the eye. Students sketch their own designs for a pressure-measuring eye device, prepare them to cond...
Each TeachEngineering lesson or activity is correlated to one or more K-12 science,
technology, engineering or math (STEM) educational standards.
All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN),
a project of D2L (www.achievementstandards.org).
In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics;
within type by subtype, then by grade, etc.
Each TeachEngineering lesson or activity is correlated to one or more K-12 science, technology, engineering or math (STEM) educational standards.
All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN), a project of D2L (www.achievementstandards.org).
In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics; within type by subtype, then by grade, etc.
Define a simple design problem reflecting a need or a want that includes specified criteria for success and constraints on materials, time, or cost.
(Grades 3 - 5)
Do you agree with this alignment? Thanks for your feedback!
Science & Engineering Practices Disciplinary Core Ideas Crosscutting Concepts Define a simple design problem that can be solved through the development of an object, tool, process, or system and includes several criteria for success and constraints on materials, time, or cost. Possible solutions to a problem are limited by available materials and resources (constraints). The success of a designed solution is determined by considering the desired features of a solution (criteria). Different proposals for solutions can be compared on the basis of how well each one meets the specified criteria for success or how well each takes the constraints into account. People's needs and wants change over time, as do their demands for new and improved technologies.
Generate and compare multiple possible solutions to a problem based on how well each is likely to meet the criteria and constraints of the problem.
(Grades 3 - 5)
Do you agree with this alignment? Thanks for your feedback!
Science & Engineering Practices Disciplinary Core Ideas Crosscutting Concepts Generate and compare multiple solutions to a problem based on how well they meet the criteria and constraints of the design problem. Research on a problem should be carried out before beginning to design a solution. Testing a solution involves investigating how well it performs under a range of likely conditions.At whatever stage, communicating with peers about proposed solutions is an important part of the design process, and shared ideas can lead to improved designs. Engineers improve existing technologies or develop new ones to increase their benefits, to decrease known risks, and to meet societal demands.
Plan and carry out fair tests in which variables are controlled and failure points are considered to identify aspects of a model or prototype that can be improved.
(Grades 3 - 5)
Do you agree with this alignment? Thanks for your feedback!
Science & Engineering Practices Disciplinary Core Ideas Crosscutting Concepts Plan and conduct an investigation collaboratively to produce data to serve as the basis for evidence, using fair tests in which variables are controlled and the number of trials considered. Tests are often designed to identify failure points or difficulties, which suggest the elements of the design that need to be improved.Different solutions need to be tested in order to determine which of them best solves the problem, given the criteria and the constraints.
Each student needs:
- 1 paper cup
- piece of string (about 2 feet, or 30 cm)
- 1 small nail
- String Telephones Worksheet
For the entire class to share:
- extra paper cups
- several 6-8 foot (1.8 - 2.3 m) pieces of string
- (optional) nylon or different types of string
- blank white paper
Have you ever noticed that you can hear sounds through solids? Everyone put your ear to you desk and scratch the surface with your fingernail. Now sit up and again scratch the desk surface. Is there a difference? (Have a few students comment, one at a time. Make sure they recognize that the sounds are louder with their ears to the desks.)
If you can hear a sound through your desk, does that mean your desk is moving? Take one minute to discuss with the people around you what is happening. (The answer is yes, tiny parts of the desk are moving with the sound wave. Refer to the slinky example in the associated lesson if more explanation is required.)
So when sound travels through a solid, it travels the same way as it does through air: in a sound wave. The sound wave actually moves the tiny particles, or molecules, that make up the solid. We now know from experience that these sound waves sound louder when we hear them through solids. If you wanted to say something to your friend on the other side of the playground, would your friend be better able to hear you through the air or through a solid? (Poll students.)
One reason engineers learn about sound waves is to design things that help people talk to each other over long distances, like the telephone, cell phone, or the internet. Engineers are helping bring the world closer together by developing technologies that enable long-distance communication. Today we are going to learn more about how sound travels using a paper cup and string. We are going to model a simple string guitar, analyze how sound moves through our model, and think about how the model relates to a telephone. Then we are going to combine our models with a partner's to make string telephones for two-way communication.
acoustics: The study of sound; the characteristics of sound in an environment.
Alexander Graham Bell: Inventor of the telephone.
communications engineering: The branch of engineering having to do with developing and maintaining technology used for communication, such as telephones.
medium: A substance that sound travels through.
Before the Activity
- Gather materials.
- Make copies of the String Telephones Worksheet.
With the Students
Explain the procedures to the students before passing out the materials.
Part 1: Model of a String Guitar
- Use a nail to make a small hole in the bottom of a paper cup (see Figure 1).
- Pull string through the cup and tie a knot (see Figure 2).
- Hold string straight out from cup with two fingers of one hand, pressing your fingernail to hold it extra tight (see Figure 3).
- Gently draw your other finger along the string, making a sound.
- Ask the students the following questions and discuss as a class: A. What do you hear? (Answer: The sound comes from your moving finger and it is quiet.) B. What do you feel? (Answer: The motionless fingers holding the string feel vibrations.)
- Now hold the cup in one hand and draw your finger along the string as before, as shown in Figure 4. Ask students the following questions, and discuss as a class.
- Where is the sound? (Answer: It is in the cup, and it is louder.) Note: This happens because the cup vibrated enough to create a sound wave in the air, which we could then hear. The hand does not vibrate enough to produce a sound.
- What happened to the vibration you felt in your hand? (Answer: It left when I transferred my hand to the cup.)
- Where do you think the vibration went? Or did it just disappear? (Answer: It went into the cup instead of my hand. It did not just disappear.)
- So why was there sound from the cup? (Answer: The vibration, or sound wave, from my finger traveled along the string and into the cup. The cup transferred the vibration into the air, which we could then hear.)
Part 2: Model of a String Telephone
- Find a partner and tie the two loose ends of your strings together.
- Stand away from each other so the string is taut.
- Speak to one another through the cups.
- Experiment with your string telephone by gently pulling the string taut and then letting it fall loose.
- Ask the students and discuss as a class:
- How does the telephone work? (Example answer: When you speak into the cup, the back of the cup vibrates; the vibration extends into the string, like a push on a slinky; the sound waves, or vibrations, move through the string.)
- Which works better: taut or loose? Why? (Answer: Taut; when the string is loose it is softer than when it is taut. Soft materials tend to absorb more sound that solid ones; when more sound is being absorbed, your friend on the other end of the line cannot hear as well.)
- What happens when the vibrations (sound waves) reach the other end of the cup? (Answer: It is the reverse of what happened on the other side: the waves in the string vibrate the cup; the vibrations from the cup disturb the air, like a pebble being thrown into still water; the vibrations in the air, otherwise known as sound waves, travel toward our ears.)
Part 3: Analyze and Improve the Model
- Have students analyze their string telephones using the following questions:
- How well did the string telephone work? (Answers will vary.)
- Where do the sound waves travel in the string telephone? (Answer: The sound waves travel from the first person's mouth, into the first cup, down the string, vibrate the second cup, and into the ears of the second person.)
- What could you do to make the string telephone work better? (Answers will vary.)
- The String Telephone Company has hired you as engineers. They want you to design a new string telephone for people who are six feet or more apart from each other. They think that this would be useful for siblings in different rooms or friends who live next door. You have 10 minutes to brainstorm with your partners and draw your new designs. You may use new materials to test your design. (Have students draw their new designs on the worksheets or blank paper.)
- Have students answer the worksheet questions.
Worksheets and Attachments
The string pulls out of the hole in the paper cups if students pull too hard. If this happens attach the string to a small paper clip to anchor it in the cup. This does not affect the sound performance.
Poll: During the introduction, ask students the following question. Tally the votes.
- Would your friend on the other side of the playground be better able to hear you through a solid or through the air?
Activity Embedded Assessment
Prediction: Before Part 2 of the activity, have students predict whether they think the string telephone will work better with a loose or taut string. Record predictions on the board.
Question/Answer: Ask students the questions found in the Procedures section. Review their answers to gauge their mastery of the subject.
Question/Answer: Ask students the following questions, allowing several to answer:
- How is a string telephone similar to a modern telephone that you would use in your house or school? (Answer: Both telephones have a receiver on each end and a path that the sound travels in the middle. However, modern telephones rely on the conversion of the sound waves into an electrical signal.)
- What are some times when communicating long distances is important? Can you think of a time when it was important for you to talk to someone far away? (Answers will vary.)
- How have telephones improved how people communicate? (Answers will vary.)
Iterate the Designs: Have students think about modifying their final string telephone designs even more. What would they do to further improve their designs? Would they change the materials for the cups or string? What might they use? Have students think about other features on telephones. What special features would they want to include on their string telephones? Give students time to draw or describe their new design ideas.
Have students compare the loudness of sound with the distance of the cups. Give them a longer length of string with which to test, and have them decrease the length of string by half each time to see if distance affects the sound. They should notice a difference, since sound waves lose strength with distance (as learned in the associated lesson). Explain to students that engineers have helped sound travel great distances by designing devices that convert the sound waves into electricity and back.
Have students try other modern telephone features on their string telephones. For example, does it work if they introduce "three-way calling" with three cups?
