Quick Look
Grade Level: 4 (35)
Time Required: 45 minutes
Expendable Cost/Group: US $0.05
Group Size: 2
Activity Dependency: None
Subject Areas: Geometry, Number and Operations, Physical Science, Problem Solving, Reasoning and Proof, Science and Technology
Summary
Students analyze and begin to design a pyramid. Working in engineering teams, they perform calculations to determine the area of the pyramid base, stone block volumes, and the number of blocks required for their pyramid base. They make a scaled drawing of the pyramid using graph paper.Engineering Connection
Ancient engineers did not have the advanced machines we have today, but they still managed to build large structures that are still around. Before the first stone is moved, engineers design structures by exploring a variety of design solutions, making drawings, building models, using mathematics and estimating material requirements. To build any huge structure, an engineer asks and finds the answers to questions such as: What is the purpose of the structure? What will be its size and shape? How will the structure support itself? What type of material(s) should be used? How much material is needed? Where is a good location to build this structure?
Learning Objectives
After this activity, students should be able to:
 Understand that engineers always make a plan before building, and that plan is called a design.
 Understand that engineers analyze a project before attempting to construct anything.
 Understand that engineers must meet the constraints of a project, such as how far stones must be moved, how large stones can be and still be able to be moved to the pyramid construction site, etc.
Educational Standards
Each TeachEngineering lesson or activity is correlated to one or more K12 science,
technology, engineering or math (STEM) educational standards.
All 100,000+ K12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN),
a project of D2L (www.achievementstandards.org).
In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics;
within type by subtype, then by grade, etc.
Each TeachEngineering lesson or activity is correlated to one or more K12 science, technology, engineering or math (STEM) educational standards.
All 100,000+ K12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN), a project of D2L (www.achievementstandards.org).
In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics; within type by subtype, then by grade, etc.
NGSS: Next Generation Science Standards  Science
NGSS Performance Expectation

35ETS11. Define a simple design problem reflecting a need or a want that includes specified criteria for success and constraints on materials, time, or cost. (Grades 3  5) Do you agree with this alignment?

Click to view other curriculum aligned to this Performance Expectation
This activity focuses on the following Three Dimensional Learning aspects of NGSS:
Science & Engineering Practices  Disciplinary Core Ideas  Crosscutting Concepts
Define a simple design problem that can be solved through the development of an object, tool, process, or system and includes several criteria for success and constraints on materials, time, or cost. Alignment agreement:  Possible solutions to a problem are limited by available materials and resources (constraints). The success of a designed solution is determined by considering the desired features of a solution (criteria). Different proposals for solutions can be compared on the basis of how well each one meets the specified criteria for success or how well each takes the constraints into account. Alignment agreement:  People's needs and wants change over time, as do their demands for new and improved technologies. Alignment agreement:
Common Core State Standards  Math

Apply the area and perimeter formulas for rectangles in real world and mathematical problems.
(Grade
4)
More Details
Do you agree with this alignment?

Apply the formulas V = l × w × h and V = b × h for rectangular prisms to find volumes of right rectangular prisms with wholenumber edge lengths in the context of solving real world and mathematical problems.
(Grade
5)
More Details
Do you agree with this alignment?

Interpret multiplication as scaling (resizing), by:
(Grade
5)
More Details
Do you agree with this alignment?

Fluently multiply multidigit whole numbers using the standard algorithm.
(Grade
5)
More Details
Do you agree with this alignment?
International Technology and Engineering Educators Association  Technology

Models are used to communicate and test design ideas and processes.
(Grades
3
5)
More Details
Do you agree with this alignment?
State Standards
Colorado  Math

Apply the area and perimeter formulas for rectangles in real world and mathematical problems.
(Grade
4)
More Details
Do you agree with this alignment?

Apply the formulas V = l × w × h and V = b × h for rectangular prisms to find volumes of right rectangular prisms with wholenumber edge lengths.
(Grade
5)
More Details
Do you agree with this alignment?

Fluently multiply multidigit whole numbers using standard algorithms.
(Grade
5)
More Details
Do you agree with this alignment?

Interpret multiplication as scaling (resizing).
(Grade
5)
More Details
Do you agree with this alignment?
Materials List
Each group needs:
 A calculator
 Pencils and erasers
 A scaled ruler
 Graph paper
 Stack It Up! Math Worksheet
Worksheets and Attachments
Visit [www.teachengineering.org/activities/view/cub_simple_lesson01_activity1] to print or download.More Curriculum Like This
Students apply the mechanical advantages and problemsolving capabilities of six types of simple machines (wedge, wheel and axle, lever, inclined plane, screw, pulley) as they discuss modern structures in the spirit of the engineers and builders of the great pyramids.
Working in engineering project teams, students evaluate sites for the construction of a pyramid. They base their decision on site features as provided by a surveyor's report; distance from the quarry, river and palace; and other factors they deem important to the project based on their team's values...
Students continue their pyramid building journey, acting as engineers to determine the appropriate wedge tool to best extract rock from a quarry and cut into pyramid blocks. Using sample materials (wax, soap, clay, foam) representing rock types that might be found in a quarry, they test a variety of...
Students investigate the ways in which ancient technologies — six types of simple machines and combinations — are used to construct modern buildings. As they work together to solve a design problem (designing and building a modern structure), they brainstorm ideas, decide on a design, and submit it ...
PreReq Knowledge
Multiplication, division, using a ruler, graph paper, and the concept of proportional scaling. General knowledge of pyramids. Familiarity with the six simple machines introduced in Lesson 1 of this unit.
Introduction/Motivation
Imagine you are the chief engineers on a pyramid construction project in ancient times. You have been given specific dimension guidelines for the pyramid: its length and width (both 120 meters) and height (72 meters). All the other decisions involving the pyramid construction are left to you. As engineers, it is your task to ensure that the new pyramid is built solidly, efficiently, and completed on time, while also making sure that it is beautiful and lasts a long time. Developing a good plan — a design — helps you meet all of these goals.
Engineers need to make sure they develop a good design that is durable and takes environmental conditions into account, such as topography and weather. However, even if you succeed in these areas, your leader will be unhappy if the project costs more than expected. Additional time and money would be wasted if you cut more rock from the quarry than needed for the pyramid or if you do not cut enough and must go back to the quarry to get more stones to finish the job. So, as engineers, you must make accurate estimations. Either overestimating or underestimating the amount of materials is unacceptable.
Engineers must also be accurate in the timeline they give to the leader. If the project takes longer than estimated, your leader will be impatient and disappointed. On the other hand, if you finish ahead of schedule, instead of being pleased that you finished so quickly, your leader might be angry about not having enough time to plan a celebration for the unveiling of the pyramid. Given such an important job, you must draw on your engineering skills to build a pyramid that pleases your leader based on how magnificent it looks, sturdy it is, quickly it is built, and efficiently it is constructed.
Procedure
Before the Activity
 Gather materials and make copies of the Stack It Up! Math Worksheet.
With the Students
 Divide the class into engineering project teams of two students each.
 Explain the concept of scaling.
 Hand out the worksheets and graph paper.
 Explain that each team's job is to use the worksheet to make detailed plans for their pyramid, and use the graph paper to make a scaled drawing of their pyramid design.
 Observe the students as they work through the worksheet calculations, helping as needed.
 Help students decide on a scale that fits the pyramid drawing optimally on the graph paper.
 Now that the students have been introduced to the design and analysis process that all engineers use to some extent, conclude the activity with a classroom brainstorming session (see the Assessment section for details). Ask the students to share with the class all the important design questions, constraints, or other topics to consider, investigate, analyze and test before building a pyramid — or any structure.
Vocabulary/Definitions
approximation: Simplifying a problem to get an answer that is close but not exact.
area: The amount of surface space (in two dimensions) that an object takes up.
design: (verb) To plan out in systematic, often graphic form. To create for a particular purpose or effect. Design a building. (noun) A well thoughtout plan.
estimate: A rough or approximate calculation.
plan: (noun) A method worked out before hand for the accomplishment of an objective.
scaling: Drawing an item smaller or larger than actual size, but keeping the same relative proportions. For example, perhaps 1 cm represents 1 meter.
topography: The surface features of a place or region.
volume: The amount of space (in all three dimensions) that an object takes up.
Assessment
PreActivity Assessment
Brainstorming: In small groups, have students engage in open discussion to generate a number of possible ideas about how the pyramids were built. Have them think about the physical processes involved (cutting and moving stone) and the mental processes (design and planning). Have one person record all proposed ideas on the classroom board. Encourage wild ideas and discourage criticism of ideas. Remind students that no idea or suggestion is "silly." All ideas should be respectfully heard.
Roundtable: Form teams of three to five students each. Ask the class how the pyramids might have been built. Have students on each team make a list, each one writing an answer and passing the paper on to the next person. Review the six types of simple machines (wedge, wheel and axle, lever, inclined plane, screw, and pulley) and ask if using any of these approaches might be helpful in the difficult work required to construct a pyramid. After students write down a few more ideas, have the teams share their responses with the class.
Activity Embedded Assessment
Worksheet: Have the students provide answers and complete the calculations on the Stack It Up! Math Worksheet. Review students' worksheet progress to gauge their mastery of the subject.
PostActivity Assessment
Closing Brainstorming: Now that students have been introduced to the design and analysis process that all engineers use to some extent, ask the students share with the class all the important design questions, constraints, or other topics to consider, investigate, analyze and test before building a pyramid — or any structure (houses, bridges, skyscrapers). Encourage wild ideas and discourage criticism of ideas. All ideas should be respectfully heard.
Troubleshooting Tips
Before students begin to write on the graph paper, make sure they have decided on a scale that fits the pyramid drawing optimally on the graph paper.
Some students may need a reminder explanation about the units for area (m^{2}) and volume (m^{3}).
For an ELL focus, use multiple sensory associations, visuals, etc.
Activity Extensions
For a class project or individual assignment, have students examine more closely the geology of Egypt and how one builds on a desert of sand.
Activity Scaling
 To increase the difficulty, use block dimensions that are harder to calculate, such as a block sized 5.0m x 2.2m x 3.7m.
