Hands-on Activity: Sensory Toys Make Sense!

Contributed by: Inquiry-Based Bioengineering Research and Design Experiences for Middle-School Teachers RET Program, Department of Biomedical Engineering, Worcester Polytechnic Institute

A photograph shows a boy examining the contents of a clear plastic water bottle that he holds with both hands. The bottle contains colored water, vegetable oil and little toy trinkets.
Toys that stimulate or integrate the senses are one way to help children interact with their environment.
copyright
Copyright © Hands On As We Grow. Used with permission. http://handsonaswegrow.com/wave-bottle-sensory/

Summary

Students design and create sensory integration toys for young children with developmental disabilities—an engineering challenge that combines the topics of biomedical engineering, engineering design and human senses. Students learn the steps of the engineering design process (EDP) and how to use it for problem solving. After learning about the human sensory system, student teams apply the EDP to their sensory toy projects. They design and make plans within given project constraints, choose materials, fabricate prototypes, evaluate the prototypes, and give and receive peer feedback. Students experience the entire design-build-test-redesign process and conclude with a class presentation in which they summarize their experiences with the EDP steps and their sensory toy project development.
This engineering curriculum meets Next Generation Science Standards (NGSS).

Engineering Connection

Engineers use their creativity to solve problems that make the world a better place for everyone. What sorts of problems do they solve? Engineers design new smartphones, large flat screen televisions and electric engines for automobiles as well as roller coasters, highway systems, artificial limbs and toy factories—and many more useful products, structures and systems! People are living longer, healthier lives today because of biomedical engineers who develop new technologies in the medical field, cures for illnesses, assistive technologies such as wheelchairs and contact lenses, new medicines and heart repairs. Like all engineers, biomedical engineers follow the steps of the EDP to find the best solutions to problems and needs that directly relate to the human body.

Learning Objectives

After this activity, students should be able to:

  • Solve an open-ended design problem.
  • Use the engineering design process to solve a problem.
  • Develop multiple solutions to a design problem.

More Curriculum Like This

Nerve Racking

Students learn about the function and components of the human nervous system, which helps them understand the purpose of our brains, spinal cords, nerves and five senses. In addition, how the nervous system is affected during spaceflight is also discussed.

Elementary Lesson
What Is a Sensor?

Students gain a rigorous background in the primary human "sensors," as preparation for comparing them to some electronic equivalents in the associated activity. Students learn the concept of "stimulus-sensor-coordinator-effector-response" to describe the human and electronic sensory processes.

Elementary Lesson
My Mechanical Ear Can Hear!

Students are introduced to various types of hearing impairments and the types of biomedical devices that engineers have designed to aid people with this physical disability. Students learn about the hearing process and ways in which hearing can be lost.

Elementary Lesson
How Do Human Sensors Work?

This lesson highlights the similarities between human sensors and their engineering counterparts. Taking this approach enables students to view the human body as a system, that is, from the perspective of an engineer. Humans have recreated most human sensors in robots – eyes, ears and sensors for te...

Elementary Lesson

Educational Standards

Each TeachEngineering lesson or activity is correlated to one or more K-12 science, technology, engineering or math (STEM) educational standards.

All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN), a project of D2L (www.achievementstandards.org).

In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics; within type by subtype, then by grade, etc.

  • Evaluate competing design solutions using a systematic process to determine how well they meet the criteria and constraints of the problem. (Grades 6 - 8) Details... View more aligned curriculum... Do you agree with this alignment?
  • Design is a creative planning process that leads to useful products and systems. (Grades 6 - 8) Details... View more aligned curriculum... Do you agree with this alignment?
  • Requirements for design are made up of criteria and constraints. (Grades 6 - 8) Details... View more aligned curriculum... Do you agree with this alignment?
  • Modeling, testing, evaluating, and modifying are used to transform ideas into practical solutions. (Grades 6 - 8) Details... View more aligned curriculum... Do you agree with this alignment?
  • Demonstrate methods of representing solutions to a design problem, e.g., sketches, orthographic projections, multiview drawings. (Grades 6 - 8) Details... View more aligned curriculum... Do you agree with this alignment?
Suggest an alignment not listed above

Materials List

Each group needs:

To share with the entire class:

  • pencils, paper (or notebooks), rulers
  • computers with internet access, for conducting research (as needed) and preparing presentations
  • a wide range of materials and fasteners for fabricating the sensory toy devices, such as various woods, plastics, metals, cardboard, rope, fabric, glue, tape, etc.
  • hand and/or machine tools for cutting, shaping, forming, joining, assembling and finishing student designs, such as rulers or tape measures, hand or power saws and drills, scissors, hot glue, super glue, etc.
  • laptop with Internet access and projector, to show the class the Visual Aids (three slides) and a four-minute online video; alternatively use an overhead projector, print the slides as handouts, or write them on the classroom board
  • PowerPoint® or Prezi (free) software for preparing and making group presentations; alternatively, provide poster board and markers

Introduction/Motivation

Think about a typical day in your life. When we get up in the morning, we spend some time getting ready for the day and right from the beginning, we start taking in information from our environment.

Your senses are a vital part of your survival system. All animals, from insects to humans, have them. A combination of receptors, neural pathways and brain parts make up the main components of the human sensory system. This system is part of the nervous system and helps us process information taken in from our surrounding environment. What are our senses? (Listen to student ideas.) That's right. Hearing, taste, sense of smell, sense of touch and vision are the primary receptors that collect information and help us learn about and interact with our world.

A cutaway medical illustration shows an outline of a human head with labels and anatomical representations of the five senses (vision-eyes, smell-nose, hearing-ears, taste-tongue, touch-spinal cord) and their connections to the brain.
Sensory nerves connect sensory organs to the brain and spinal cord.
copyright
Copyright © US National Library of Medicine, National Institutes of Health www.ncbi.nlm.nih.gov

Sometimes, however, peoples' sensory systems do not function the way they should and the information they take in is not processed as intended. This can affect a person's daily life and make his or her everyday experiences and learning quite different or even difficult at times. For example, some people have sensory processing disorder (SPD). Common daily tasks can be a challenge to perform for people with SPD because they have difficulty and/or problems processing sensory stimuli. Muscular coordination, behavioral problems, anxiety, depression and failure in school may be the result of sensory processing disorder. How can we help?

Vocabulary/Definitions

auditory: Of or relating to the sense of hearing.

biomedical engineering: Solving problems in biology and medicine using engineering concepts and practices.

constraint: A limitation or restriction. For engineers, constraints are the limitations and requirements that must be considered when designing a workable solution to a problem.

criteria: In engineering design, the objectives and requirements that a final design solution is required to meet.

engineering design process: A creative, organized and cyclical process that guides engineers in developing solutions to problems.

gustatory: Of or relating to the sense of taste.

olfactory: Of or relating to the sense of smell.

sensory integration: The process of using the information gained from the sensations coming from within the body and outside the body.

sensory system: A system of receptors and pathways that take in external stimuli and send it to the brain to be processed.

tactile: Of or relating to the sense of touch.

vision: Of or relating to the sense of sight.

Procedure

Background and Overview: The focus of this design project is the application of the engineering design process (EDP) to develop a sensory toy. The objective of a sensory toy is to stimulate selected human senses; it need not have a recreational or educational purpose. For example, a child plays with a sensory toy such as a multi-colored foam cube because the colors stimulate vision and squeezing the foam provides a tactile sensation. (If you use some of this information to introduce the project, be mindful not to give project design ideas to students.)

A photograph of a sensory toy shows a ring made of clear plastic tubing covered with scattered stripes of tape in bright colors with moving bells and balls inside the tube.
Simple sensory toys are designed to stimulate visual, auditory and tactile senses.
copyright
Copyright © 2014 Thomas Oliva, RET Program, Worcester Polytechnic Institute

EDP: To adequately guide and coach students, it is best if the instructor has a good working knowledge of the engineering design process. The EDP steps provided in slide 1 of the Visual Aids are from the Massachusetts curriculum frameworks, but other versions of the EDP can also be used. This project is intended to closely follow all the steps of the EDP.

Tools: The design project also makes use of a general shop (or a design/prototyping/fabrication/maker shop or lab) with a variety of hand and/or power tools. If one is not available, the activity can be conducted in a typical classroom, but may require some modifications. Lack of these resources may make this project challenging to complete.

Materials: No restrictions are provided on the kind or type of materials used for the design project and students choose their own materials. However, the selected materials must adhere to the project constraints for cost, weight and safety, etc. The teacher may want to alter the constraints and/or limit material choices based on the budget and/or availability of tools to necessary to work with certain materials. Having knowledge of material properties is helpful to guide students if questions or problems arise during the process of selecting project materials.

Before the Activity

  • Gather any materials or fasteners that you think students may need during this project. Materials might include a wide assortment of fabric, plastics, wood, metal, cardboard and other materials. Students may also bring in their own supplies and materials. On Day 3, students generate a detailed list of supplies, materials and tools needed to fabricate their designs starting on Day 4; the items can be obtained by a combination of already available items, items from home, materials found in recycling/scrap bins and specific teacher purchases. Alternatively, if you do not have access to a wide variety of fasteners and materials, consider giving students a short list from which they choose, which becomes the teacher's shopping list. It is up to the teacher's discretion how to source and limit the supplies, materials and tools.
  • Make copies of the EDP Pre/Post-Test, Sensory Toy Research Sheet, Me and My Senses Activity Sheet, Sensory Integration Reading, Sensory Toy Evaluation Sheet and Sensory Toy Presentation Scoring Rubric.
  • If desired, establish work groups. Student pairs may either work together from the start or beginning with the research component on Day 2.
  • Prepare a laptop and projector to show the class the Visual Aids, three slides in a PowerPoint® file, as well as a four-minute online video. Alternatively, use an overhead projector, slides printed out as handouts or written on the classroom board. Show slides 1 and 2 on Day 1, and slide 3 and the video on Day 2.

With the Students—Day 1: Identify the Problem

  1. Administer and collect the pre-test, as described in the Assessment section.
  2. Present to the class the Introduction/Motivation content.
  3. With students ready with pencils and paper (or notebooks), show the class the engineering design process graphic (slide 1 of the Visual Aids) to introduce (or review) the steps of the engineering design process (EDP). Have students copy down the following in their notebooks:
  • EDP steps: Identify the problem or need, research the problem, develop possible solutions, select the best solution, create a prototype, test the prototype, communicate the results, redesign.
  1. Present the engineering design challenge by showing the class the sensory toy project design criteria (slide 2 of the Visual Aids). Introduce the problem statement and its constraints. For engineers, constraints are the limitations and requirements that must be considered when designing a workable solution to a problem. Have students write the constraints in their notebooks.
  • Problem statement: Design a sensory integration toy for a child with developmental disabilities.

The device must:

  • be safe
  • be durable
  • cost less than $10
  • weigh less than 2 pounds
  • be completed in 2 weeks (flexible based on available time)
  • not be messy or make a mess
  • target 2 of the following senses: visual, auditory or tactile
  1. Connect the problem statement to step 1 of the engineering design process: identify the problem or need. Explain that it is important to clarify the statement of need before beginning to design.
  2. Provide some time for any questions and discussion about the EDP and project criteria.

With the Students—Day 2: Research the Problem

  1. Divide the class into groups of two students each.
  2. Have student pairs conduct online research (as necessary) to answer the 11 project-specific research questions about the human sensory system provided on the Sensory Toy Research Sheet.
  3. Show students the 3:41-minute Human Senses video clip at https://www.youtube.com/watch?v=ALw-xcKy4Gc.
  4. Have students individually complete the Me and My Senses Activity Sheet. Students are asked to think of examples of sensory stimulus that they commonly encounter (what they hear, see, smell, taste, touch) to heighten their awareness of the importance of sensory integration.
  5. Have the class read the Sensory Integration Reading (which doubles as a literacy activity). Lead a class discussion about the information in the reading. Show students the three discussion questions provided on slide 3 of the Visual Aids:
  • What is the most important sentence in the first paragraph?
  • Does sensory integration remain the same throughout your life?
  • What is one disadvantage that may occur for people who have a problem with sensory integration?
  1. After this, if needed, give students additional research time on the computers.

With the Students—Day 3: Develop Possible Solutions and Select the Best Solution

  1. Direct the groups to begin brainstorming ideas for sensory toys. To spark ideas, have them reflect on and refer to their research from Day 2. Require teams to identify TWO specific functions that their toys will accomplish; each device must stimulate at least two of the following three senses: visual, auditory and tactile. If students are stuck, ask the Investigating Questions to help them brainstorm ideas. Encourage students to take lots of notes about their ideas, make many sketches and consider potential materials. Require them to develop at least two different plans for possible toy designs.
  2. Have teams compare their best design solutions, critically evaluating them to determine which best meets the criteria and constraints of the design challenge. Then have each group make a final sketch and plan of its best solution to show the teacher for approval.
  3. Review groups' selected best designs and give approval after affirming that the design meets all criteria. Explain any unmet criteria and direct students to redesign as necessary. Continue to work with student groups to review/approve designs as they evolve.
  4. As students begin to identify materials, working off a final multi-view sketch labeled with material details and dimensions, have them prepare a detailed list of what materials and how much of each are required by the design. Working with the groups, make a plan to obtain the necessary materials and tools before the next day of the project.
    Two photographs: A boy at a workbench draws on paper; a tape measure is nearby. A girl wearing safety glasses cuts wood with a band saw.
    Developing a device design involves careful planning to meet all project criteria and then using tools and materials to create a prototype.
    copyright
    Copyright © 2014 Thomas Oliva, RET Program, Worcester Polytechnic Institute

With the Students—Days 4-8: Build a Prototype

  1. Provide groups with the necessary materials, tools and guidance to build and then evaluate their prototypes. The fabrication of the prototypes is exclusively the responsibility of students working on this step of the design process; give students the freedom to self-direct the process. Expect that all students will not finish at the same time due to the variability in design complexity and degree of focus on task. Flexibility with time may be necessary.
  2. During this phase, the instructor (and any other adult assistants) serves as a lab monitor to help with supplies and materials, assists with any problems that arise, and oversees student use of tools and machines. As needed, provide specific instruction, training and safety guidelines for the tools and equipment students will use.
    A photograph shows a child playing with a toy made from a clear plastic bottle that is partially covered with colored tape and contains bells and small balls.
    A child plays with a toy designed to stimulate visual and auditory senses.
    copyright
    Copyright © 2014 Thomas Oliva, RET Program, Worcester Polytechnic Institute

With the Students—Days 9-10: Test the Prototype, Communicate Results and Redesign

  1. At this stage, students play with their prototypes to attain and confirm functionality (safe, durable, appealing, engaging, stimulating) and submit their prototypes to peer review for evaluation against the original constraints (device cost, safety, weight, etc.) and specific functions identified by the designing team.
  2. Have each toy be evaluated by five students using the Sensory Toy Evaluation Sheet to keep track of the feedback. Instructions are on the sheet. Any redesign modifications made from testing results and peer feedback are part of the continuing cyclical EDP to create the best solution possible.
  3. Direct the teams to prepare and make presentations to the entire class that document their team progress through the steps of the EDP and fully explain the resulting sensory toy device. Hand out the Sensory Toy Presentation Scoring Rubric so students understand the expectations. Inform students of the presentation requirements, as described in the Assessment section.
  4. Administer and collect the post-test, as described in the Assessment section.

Attachments

Safety Issues

Use the following guidelines to ensure student safety in a fabrication environment.

  • Train students on the correct and safe use of hand and power tools.
  • Wear safety glasses when using hand and power tools.
  • Expect correct and safe behavior at all times in the shop area.

Investigating Questions

  • What types of things stimulate or integrate human vision? (Answer: Bright colors, contrasting colors and movement can stimulate vision.)
  • What types of things stimulate or integrate human hearing? (Answer: Loud noises, ringing and music can stimulate hearing.)
  • What types of things stimulate or integrate human touch? (Answer: Varying textures such as a rough surface like sandpaper.)

Assessment

Pre-Activity Assessment

Engineering Design Process Test: Before starting the activity, administer the seven-question EDP Pre/Post-Test to gauge students' base knowledge. This could be done a day or two before starting the activity.

Activity Embedded Assessment

Reflection Questions: During design and development, have students spend time reflecting on and answering the items listed below; these questions are intended to be formative. Either ask students to write down their answers for teacher review, or check their understanding through student/teacher discussion. Either way, the answers are designed to help students keep continual focus on the design process. Student answers also indicate whether they understand how the design process works. End each class period by having students do an exit activity or self-evaluation to monitor daily understanding and project progress. Expect teams to progress at different rates, with every group eventually addressing and achieving all the items below.

  1. State how your design addresses the project criteria: The toy must:
  • be safe
  • be durable
  • cost less than $10
  • weigh less than 2 pounds
  • be completed in 2 weeks (flexible based on available time)
  • not be messy or make a mess
  • target 2 of the following senses: visual, auditory or tactile
  1. Which of your two proposed designs did you choose? Why?
  2. Explain how or why your design addresses the two senses you selected.
  3. How do you determine whether something works or does not work?
  4. Does the toy design achieve the intended objective?

Design Approval: Review teams' chosen designs to confirm that the project criteria have been met. This can be done with a simple checklist. Explain any unmet criteria so students can adjust (redesign) before submitting for teacher review again. Once approved, groups can move on to the next step.

Post-Activity Assessment

Group Project Presentations: After testing and peer evaluation are completed, direct the groups to prepare and make presentations to the entire class that document their team progress through the steps of the EDP and fully explain the resulting sensory toy device.

  • Give each team a copy of the Sensory Toy Presentation Scoring Rubric so they understand the expectations while preparing the presentations.
  • Require the presentation to include a title slide and one slide for each of the eight steps of the EDP so students can explain how they went from a problem to ideas to a useful solution. The slide for EDP step 8: redesign, can include ideas for possible future improvements to the design.
  • Require teams to demonstrate their final sensory toy prototypes.
  • Encourage the use of images (sketches, photographs) to document progress throughout the design process, as well as detailed design information in the form of descriptions, labeled drawings, dimensions, material identification, constraints and target functions.
  • Grade each team presentation and project using the scoring rubric.

Engineering Design Process Test: At activity end, administer the seven-question EDP Pre/Post-Test again, comparing pre/post scores to gauge changes in student comprehension.

Activity Extensions

Challenge students to develop marketing plans for their sensory toys. This could involve developing an accurate cost (for example, within 2%), identifying a target client group and creating an advertisement or brochure for the toy.

Assign students to research specific developmental or other disabilities that have a connection to sensory integration. Examples include autism, sensory integration disorder, attention deficit disorder, etc.

Activity Scaling

For upper grades:

  • In addition to developing marketing plans for the toys (see the Activity Extensions section), have students map out plans to mass produce their toys, detailing each process involved and all associated material and labor costs. Also require them to develop packaging and shipping plans.
  • Have students make video clips that teach younger students about the five human senses and how important each one is in daily life.
  • Have students interview an occupational therapist to see how s/he helps students with sensory integration problems.

Additional Multimedia Support

The online source of the provided graphic of the steps of the engineering design process is the Massachusetts Curriculum Framework (Strand 4: Technology / Engineering) at http://www.doe.mass.edu/frameworks/scitech/2001/standards/strand42.gif.

During Day 2, show students a 3:41-minute YouTube video, Human Senses, by Bellerbys College in Oxford, UK, at https://www.youtube.com/watch?v=ALw-xcKy4Gc.

References

Science and Technology/Engineering Curriculum Framework. Last updated May 1, 2001. Massachusetts Department of Elementary and Secondary Education (archived information). Accessed December 2014. (Great background information about the relationship between science, engineering and technology, as well as the steps of the engineering design process) http://www.doe.mass.edu/frameworks/scitech/2001/standards/strand4.html

Sensory Development – Touch, Taste and Smell, Movement Sensations, Auditory System, Visual System, Sensory Systems in Concert – Body Position Sense. Net Industries. Accessed December 2014. http://social.jrank.org/pages/563/Sensory-Development.html

Sensory Systems. Last updated May 16, 2005. The Human Physiology, Biology Online. Accessed December 2014. http://www.biology-online.org/9/8_sensory_systems.htm
