Curricular Unit: Using Stress and Strain to Detect Cancer!

Contributed by: VU Bioengineering RET Program, School of Engineering, Vanderbilt University

An arrow points to a whitish area in a black and white image, a mammogram.
A mammogram shows a tumor.
copyright
Copyright © National Institutes of Health (public domain image)

Summary

Students are presented with a biomedical engineering challenge: Breast cancer is the second-leading cause of cancer-related death among women and the American Cancer Society says mammography is the best early-detection tool available. Despite this, many women choose not to have them; of all American women at or over age 40, only 54.9% have had a mammogram within the past year. One reason women skip annual mammograms is pain, with 90% reporting discomfort. Is there a way to detect the presence of tumors that is not as painful as mammography but more reliable and quantifiable than breast self-exams or clinical breast exams? This three lesson/three activity unit is designed for first-year accelerated or AP physics classes. It provides hands-on activities to teach the concepts of stress, strain and Hooke's law, which students apply to solve the challenge problem.
This engineering curriculum meets Next Generation Science Standards (NGSS).

Engineering Connection

Today, medical imaging is generally accepted as a safe, noninvasive means of generating internal images of the body. More than 100 years ago, such beneficial uses of harmful radiation would have been dismissed as outrageous and impossible. Decades of work by doctors, radiologists, scientists and engineers has provided safer use of x-rays for imaging of the skeletal system and some soft tissue, computer axial tomography, CT scans, to obtain three dimensional x-ray based imaging, magnetic resonance imaging, MRI, for depicting high contrast in soft tissues, and ultrasound imaging using high-frequency sound waves to depict moving structures and tissues in real time. Unfortunately, challenges remain in medical imaging today; one of which is presented in this unit. With nearly 45% of women avoiding annual mammograms due to pain and discomfort, students are challenged to think like engineers to develop a painless means of breast cancer detection that is reliable, cost effective and noninvasive.

More Curriculum Like This

Detecting Breast Cancer

Students are introduced to the unit challenge: To develop a painless means of identifying cancerous tumors. Solving the challenge depends on an understanding of the properties of stress and strain. After learning the challenge question, students generate ideas and consider the knowledge required to ...

High School Lesson
Presenting Painless Breast Cancer Detection!

This lesson culminates the unit with the Go Public phase of the legacy cycle. In the associated activity, students depict a tumor amidst healthy body tissue using a Microsoft Excel® graph.

Tell Me the Odds (of Cancer)

Through four lessons and three hands-on activities, students learn the concepts of refraction and interference in order to solve an engineering challenge. Students learn about some high-tech materials and delve into the properties of light, including the equations of refraction (index of refraction,...

Stress, Strain and Hooke's Law

Students are introduced to Hooke's law as well as stress-strain relationships. Through the lesson's two-part associated activity, students 1) explore Hooke's law by experimentally determining an unknown spring constant, and then 2) apply what they've learned to create a strain graph depicting a tumo...

Educational Standards

Each TeachEngineering lesson or activity is correlated to one or more K-12 science, technology, engineering or math (STEM) educational standards.

All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN), a project of D2L (www.achievementstandards.org).

In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics; within type by subtype, then by grade, etc.

  • Analyze a major global challenge to specify qualitative and quantitative criteria and constraints for solutions that account for societal needs and wants. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Design a solution to a complex real-world problem by breaking it down into smaller, more manageable problems that can be solved through engineering. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Calculate and interpret the average rate of change of a function (presented symbolically or as a table) over a specified interval. Estimate the rate of change from a graph. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
Suggest an alignment not listed above

Unit Overview

The unit's design uses a contextually based "Challenge" followed by a sequence of instruction in which students first offer initial predictions ("Generate Ideas") and then gather information from multiple sources ("Multiple Perspectives"). This is followed by "Research and Revise" as students integrate and extend their knowledge through a variety of learning activities. The cycle concludes with formative ("Test Your Mettle") and summative ("Go Public") assessments that lead the student towards answering the Challenge question. See the unit overview below for the progression of the legacy cycle through the unit. Research and ideas behind this way of learning may be found in How People Learn, (Bransford, Brown & Cocking, National Academy Press, 2000); see the entire text at http://www.nap.edu/html/howpeople1/.

The legacy cycle has similarities to the engineering design process; they both involve identifying needs existing in society, combining science and math to develop solutions, and applying the research conclusions to design clear conceived solutions to the challenges. Though the engineering design process and the legacy cycle depend on a correct and accurate solution, each focuses particularly on how the solution is devised and presented. See an overview of the engineering design process at http://en.wikipedia.org/wiki/Engineering_design_process.

In lesson 1, students are presented with the following Grand Challenge: "Breast cancer is the second-leading cause of cancer death among women (Papas, 253) and the American Cancer Society has indicated that mammography is the best early-detection tool available. Despite the fact that mammograms are the most effective early-detector of breast cancer, many women choose not to have them. Of all American women at or over the age of 40, only 54.9% have had a mammogram within the past year (ACS, 15). One reason women attribute skipping their annual mammogram is pain with 90% report experiencing discomfort (Papas, 254). Is there a way to detect the presence of tumors that isn't as painful as mammography but more reliable and quantifiable than a breast-self exam and clinical breast-exams?"

Students begin by Generating Ideas in lesson 1's associated activity, answering questions such as, "What are your initial thoughts about how this question can be answered?" and "What do you know about breast cancer and tumor detection already?" Students then enter the Multiple Perspectives phase of the legacy cycle as they read an expert interview from a professor of biomedical imaging. To extend the Multiple Perspectives phase, it is suggested that a local specialist make a guest presentation on medical imaging to the class.

In lesson 2, students enter the Research and Revise phase focusing on the concepts of Hooke's law and stress-strain relationships. The lesson includes a problem set to complete individually or as a class. The practice problems give students experience manipulating the new equations. Students extend their understanding of these concepts in the associated activity. In the first portion of the activity, students explore Hooke's law by experimentally solving for an unknown spring constant. In the second portion of the activity, students apply this understanding to study breast tissue with respect to cancer detection. After completing the lesson and the associated activities, students enter the Test Your Mettle phase by completing a quiz on stress, strain and Hooke's law.

Finally, lesson 3 and its associated activity constitute the Go Public phase of the legacy cycle. First, in the associated activity, students create a graph in Excel® depicting the location of a cancerous tumor amidst healthy breast tissue. This in-class assignment constitutes one-half of the grade while the other half results from a take-home assignment. In the take-home assignment, students are create informative brochures presenting their innovative, painless form of breast cancer detection to patients and physicians.

Unit Schedule

Assessment

Lesson 3 and its associated activity constitute the final Go Public phase of the legacy cycle during which students apply the concepts they have learned to answer the Grand Challenge question. They relate the learned concepts of Hooke's law, stress and strain to medical imaging. This summative assessment covers the previous two lessons and their associated activities.

Contributors

Meghan Murphy; Luke Diamond

Copyright

© 2013 by Regents of the University of Colorado; original © 2007 Vanderbilt University

Supporting Program

VU Bioengineering RET Program, School of Engineering, Vanderbilt University

Acknowledgements

The contents of this digital library curriculum were developed under National Science Foundation RET grant nos. 0338092 and 0742871. However, these contents do not necessarily represent the policies of the NSF, and you should not assume endorsement by the federal government.
