Lesson: Manned Mission to Mars

Contributed by: Integrated Teaching and Learning Program, College of Engineering, University of Colorado Boulder

Photo shows a tethered astronaut "floating" in space.
Students explore mars
copyright
Copyright © 2004 NASA http://grin.hq.nasa.gov/

Summary

Students are immersed in the details for a possible future manned mission to Mars. They learn about the human safety risks that are evaluated and addressed to minimize danger to astronauts. They examine a specialized launch schedule and the varied backgrounds and professions of the crew. Students find out about the crew's activities and living conditions once on the Martian surface, as well as how to make enough fuel to make it off the Red Planet to return home.

Engineering Connection

Engineers know that risks are always present in the exploration of space — just as in our daily lives. Are you at risk when you take an escalator, elevator, airplane, bus or amusement park ride? Are you safe when you use your washing machine, blender, drill, furnace or lawn mower? While some level of risk will always exist in our daily activities, safety engineers do their best to minimize risks through smart design and extensive testing transportation, appliances, equipment and products.

Learning Objectives

After this lesson, students should be able to:

  • Explain the varied risks and environments of a planetary mission.
  • Recognize the different professions of the crew.
  • Describe advantages and disadvantages to planning manned missions to Mars.
  • Explain how future missions to Mars may affect science and society.

More Curriculum Like This

Destination Outer Space

Students acquire a basic understanding of the science and engineering of space travel as well as a brief history of space exploration. They learn about the scientists and engineers who made space travel possible and briefly examine some famous space missions. Finally, they learn the basics of rocket...

Elementary Lesson
The Amazing Red Planet

Students are introduced to the planet Mars. They begin by discussing the location and size of Mars relative to Earth, as well many interesting facts about this "red planet." Next, the history of Martian exploration is reviewed and students discover why researchers are so interested in studying this ...

Middle School Lesson
Blast Off

Rockets need a lot of thrust to get into space. Students learn how rocket thrust is generated with propellant. The two types of propellants are discussed—liquid and solid—and their relation to their use on rockets is investigated. Students learn why engineers need to know the different properties of...

Elementary Lesson
Robots on Ice

Students learn about humankind’s search for life in outer space and how it connects to robotics and engineering. This lesson provides students with intriguing information about far off (distance and time!) space missions and field robotics, and also sets up two associated robotics and arts integrati...

Middle School Lesson

Educational Standards

Each TeachEngineering lesson or activity is correlated to one or more K-12 science, technology, engineering or math (STEM) educational standards.

All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN), a project of D2L (www.achievementstandards.org).

In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics; within type by subtype, then by grade, etc.

  • Knowledge gained from other fields of study has a direct effect on the development of technological products and systems. (Grades 6 - 8) Details... View more aligned curriculum... Do you agree with this alignment?
  • Brainstorming is a group problem-solving design process in which each person in the group presents his or her ideas in an open forum. (Grades 6 - 8) Details... View more aligned curriculum... Do you agree with this alignment?
Suggest an alignment not listed above

Introduction/Motivation

In January of 2004, President Bush proposed an ambitious plan to return Americans to the moon by 2020 to serve as a steppingstone for future manned missions to Mars as early as 2030. Traveling first to the moon allows for easier and more cost effective experimentation with launching larger and heavier spacecraft because the moon has low gravity and no atmosphere.

Risks are always present in the three environments of planetary missions: active space, in-space and planetary surface. The active space environment includes launches and landing; the in-space environment includes time spent in zero gravity; and the planetary surface environment includes any potential hazards on the surface after landing. Since cargo is not affected by the in-space environment, it is sent at a slow rate ahead of time to provide safety for the future crew. These environments are discussed in greater detail in the Lesson Background section.

The crew for future missions to Mars will consist of several people who are trained in a wide range of fields, including mechanical and electrical engineering, medicine, geo-science and bio-science. They will spend their time conducting experiments and helping us learn about the Mars environment. Most of these experiments will be planned before they leave Earth, and the materials will be sent to space ahead of them. The crew will also need to be resourceful; they must be able to make their own methane/oxygen propellant fuel on the surface of Mars in order to return to Earth.

Though it may seem a long time away, it is very likely that there will be a person on Mars in your lifetime! Maybe you could be the first person to walk on Mars! Just remember, if you do decide to go to Mars, it is a perilous two and a half year round-trip journey.

Lesson Background and Concepts for Teachers

Risk Assessment

Three levels of risks are associated with almost any mission or activity: low, intermediate and high. And, astronautson planetary missions encounter three environments: active space, in-space, and planetary surface.

The active space environment is a high-risk environment that involves the energetic portions of the mission such as launch, orbital maneuvering, atmospheric entry and landing. The active space environment occurs on both Earth and Mars. The only fatal accidents from US and Russian spacecraft have occurred in the active space environment.

As the name suggests, the in-space environment occurs in space while astronauts are in transit from one planet to another. This environment poses an intermediate risk to astronauts, which comes from radiation exposure, consisting of galactic cosmic rays and solar particle events, and the zero gravity environment, which can harm the human body after prolonged amounts of time.

The planetary surface environment is the lowest-risk environment because Mars itself provides both gravity and protection from radiation. Though the gravity is equal to about 1/3 of the Earth's, it will help recover any zero gravity effects from the in-space environment. The Martian atmosphere and day/night cycle will drastically reduce the solar particle radiation while the planet itself will act as a shield against galactic cosmic rays.

It is important to note that the level of risk of an accident occurring in any environment is hard to quantify, but the probability is lessened by extensive astronaut training and equipment testing. Also, realistically, some level of risk will always be present — no matter how well planned or well executed a mission is. For example, the active space environment is inherent to the mission and cannot be avoided. Finally, with all the levels of risk evaluated, the safest mission with the most productivity occurs by reducing astronauts' time in transit and maximizing their time on Mars.

Launches

Photo shows a space shuttle blasting off from Earth.
Figure 1. A shuttle is launched into space.
copyright
Copyright © NASA http://nssdc.gsfc.nasa.gov/planetary/mars/image/bigenerg.gif

Assuming NASA has the technology, equipment and funding, the crewed missions will involve six launches over two years. For example, three launches of cargo would be sent to Mars in a slow-transit trajectory in 2030 to provide safety and help extend the stay of the future crew. The cargo would consist of an Earth return vehicle (ERV), two nuclear power modules, a surface laboratory, a Mars ascent vehicle (MAV), a liquid oxygen/methane propellant production module, two utility trucks, tools, spare parts, a supply of liquid hydrogen, and more! Since the in-space environment does not affect cargo, a slow transit will be used to save money.

Before the next launches could happen in 2032, the previous cargo launches will have to be confirmed successful before a human crew is sent to Mars. Once that success is affirmed, three more launches will occur. Two of the launches will be similar to the 2030 launches with a backup ERV, a second oxygen/methane propellant module, more liquid oxygen, and more scientific equipment. Finally, the third launch will be manned and on a fast-transit trajectory.

The crew will consist of 6 or 7 expert individuals trained in several different disciplines, including: mechanical and electrical engineering; general medicine including surgery, psychology and biomedicine; geology, geophysics, paleontology and geochemistry; and biology, botany and ecology. However, every crew member will need to demonstrate skills in management, communications, computer science, navigation and journalism.

On the Surface

During their 500+ day stay, the crew is responsible for trying to answer as many unknown questions about Mars as possible. This includes investigating the existence of life and water on Mars. They will conduct many previously planned experiments while staying in contact with a support team on Earth. The support team helps to evaluate their findings while aiding in instruction for future experiments.

While on Mars, the crew will spend most of its time in a habitat module and surface laboratory module (see Figure 2). Both modules have the same cylindrical design and are 7.5 meters in diameter with two sections, both 3 meters high. The modules are powered by the nuclear power modules, which will be placed 1 km away from the modules. For long surface explorations, pressurized rovers may be used for up to several weeks at a time. For shorter surface activity, up to 6 to 8 hours, unpressurized rovers will be used and extravehicular activity (EVA) suits must be worn.

Artist's rendering shows two squat cylindrical objects, each with wheels and legs, and a red surface.
Figure 2. A habitat module joined to a surface laboratory module.
copyright
Copyright © NASA http://nssdc.gsfc.nasa.gov/planetary/mars/image/bighab.gif

Return to Earth

To get back to Earth, methane (CH4) and oxygen (O2) propellant must be made on the surface of Mars. Since the atmosphere of Mars is 95.3% carbon dioxide (CO2), the liquid hydrogen (H2) cargo can be used to produce methane and water (H2O) in the following reaction:

CO2 + 4H2 → CH4 + 2H2O

While the methane is stored for fuel, the H2O is further broken down into hydrogen and oxygen:

2H2O → 2H2 + O2

Now the oxygen is stored for fuel and the hydrogen in recycled back into the first process.

When enough propellant is made, approximately 26 metric tons, the mars ascent vehicle (MAV) will take off from the surface and go into orbit around Mars. While in orbit, the MAV will dock with the ERV, which by now has been orbiting around Mars for four years. The ERV is composed of a propulsive stage, transit module, and Earth entry capsule (EEC). To reduce cost and provide familiarity and safety, the transit module has a design identical to the habitat and laboratory module. During the 180 day return trip, the crew must condition themselves for the 1 gravity environment back on Earth. Several days before arrival, the propulsion stage and transit module will be jettisoned and the crew will slightly alter their trajectory and reenter the Earth's atmosphere (much like the Mercury and Apollo missions).

An artist's drawing shows a base structure on a red surface with a pointed capsule in the air above it.
Figure 3.The Mars ascent vehicle launching off the surface of Mars.
copyright
Copyright © NASA http://nssdc.gsfc.nasa.gov/planetary/mars/image/bigascnt.gif
An artist's drawing shows a pointed capsule approaching a larger cylindrical station with side solar panels.
Figure 4. The Mars ascent vehicle as it prepares to dock with the Earth return vehicle.
copyright
Copyright © http://nssdc.gsfc.nasa.gov/planetary/mars/image/bighab.gif

Vocabulary/Definitions

Active space environment: High-risk environment that involves energetic portions of the mission (such as launching and landing).

EEC: The Earth entry capsule is used to reenter the Earth's atmosphere.

ERV: The Earth return vehicle is planned to be sent to Mars ahead of time and orbit around the Red Planet with enough provisions to make it back to Earth.

in-space environment: Intermediate-risk environment due to radiation and zero gravity.

MAV: The Mars ascentvehicle will use a methane and oxygen propellant to launch from the surface into an orbit around Mars.

planetary surface environment: Low-risk environment on the surface of Mars that offers protection against the in-space risks.

Associated Activities

  • Are We Alone? - Acting as Martian explorers, students conduct scientific experiments in which they evaluate three soil samples and determine if any of the planet's soil samples contain life.

Lesson Closure

Is there anything risky about humans traveling to other planets? (Listen to student answers.) What are dangerous environments for humans on planetary missions? (Listen to student answers.) That's right, we evaluated the risks involved with the three planetary mission environments: active space, in-space and planetary surface. Which is the highest risk? The active space environment cannot be avoided and has the highest risk, whereas the in-space environment has an intermediate risk and the planetary surface environment has the lowest risk. Since cargo is not affected by the in-space environment, it is sent at a slow rate ahead of time to provide safety for the future crew.

What type of person would you want on your crew if you were going on a space mission? You'll want people from a range of backgrounds, including mechanical and electrical engineering, medicine, geology, and biology. And, every crew member needs skills in management, communications, computer science, navigation and journalism.

Would you be worried about getting back to Earth? What have engineers planned as a way the crew can leave Mars and return to Earth? (Listen to student answers.) That's right, to get back to Earth, the crew must make their own fuel — a methane/oxygen propellant — while on the surface of Mars. How will they do this? They will use the liquid hydrogen cargo to convert the carbon dioxide atmosphere into methane and water. The water is then decomposed into oxygen and hydrogen, which can be reused. Once enough propellant is made, the Mars ascent vehicle (MAV) can launch from the surface into Martian orbit and dock with the orbiting Earth return vehicle (ERV). Are you ready to go?

Assessment

Pre-Lesson Assessment

Brainstorming: In small groups, have students engage in open discussion. Remind them that in brainstorming, no idea or suggestion is "silly." All ideas should be respectfully heard. Encourage wild ideas and discourage criticism of ideas. Ask the students:

  • What makes a manned mission to Mars so difficult to accomplish? (As necessary, to get the brainstorm going, suggest one or two of the following consideratiosn: the great distance Mars is from the Earth, the long time required to send an astronaut round-trip, the enormous cost of the mission, the amount of food, air, and supplies needed to survive, and having fuel to return to Earth.)

Post-Introduction Assessment

Question/Answer: Ask students the following questions and have them raise their hands to respond. Write their answers on the board

  • Why is reinstating the manned moon missions beneficial to preparing to conduct future space exploration? (Answer: To make it easier and more cost effective to experiment with and learn about launching larger and heavier spacecraft.)
  • How long would a round trip to Mars take? (Answer: About 2 ½ years.)

Lesson Summary Assessment

Risk Assessment: As a class, assess the risks associated with planetary missions. On the board, list the three environments and short definitions of a planetary mission. Make sure students understand the differences between the three.

  • Active Space Environment – High-risk environment that involves energetic portions of the mission (such as launching, landing, atmospheric re-entry).
  • In-Space Environment – Intermediate-risk environment due to radiation and zero gravity (such as health affects, etc).
  • Planetary Surface Environment – Low-risk environment on the surface of Mars that offers protection against the in-space risks (such as different oxygen levels. protection for radiation, etc).

Next, as a class, brainstorm a list of what risks might be involved in each of the environments. From these lists, students will then come up with an assessment for the risks involved in space flight. Have them rank the risks in order of least harmful (1), to moderately harmful (3), to most harmful (5) for each environment, with 2 and 4 falling between their lower and higher ranking. For example, if there are 5 risks associated with active space environment and they are numbered 1-5, the sum of those risks rankings equals 15. However, if a flight only experiences risk 1 and 3 on their journey, then they have a flight sum score of 4. Their fight risk ratio is 4:15. Depending on their scale, a 4 might be considered a successful mission, while a 9 (for a different flight) might be considered a very unsuccessful mission. Let the students determine the magnitude of their scale. Students should come up with 3-4 flight missions that they name and then evaluate.

Class Debate: Split the class into two groups. Have one group argue for (agree with) the topic and one group argue against (disagree with) the topic. Give the groups a few minutes to come up with their arguments before the class debate or, time permitting, give them a night to research their arguments.

  • Topic: Future manned missions to Mars will change society for the better. (Example arguments: students that are for the topic might discuss engineering and science advances; students against the topic might discuss the incredible financial expense to citizens.)

Numbered Heads: Break the class up into teams of three to five. Have the students on each team pick numbers (or number off) so each member has a different number. Ask the students a question (give them a time frame for solving it, if desired). The members of each team should work together to answer the question. Everyone on the team must know the answer. Call a number at random. Students with that number should raise their hands to give the answer. If not all the students with that number raise their hands, allow the teams to work a little longer. Ask the students:

  • What are the three environments encountered in a planetary mission? (Answer: active space, in-space, planetary surface)
  • Rank the environments from lowest to highest risk. (Answer: planetary surface, in-space, active space)
  • Why is it safer to send cargo to Mars ahead of time? (Answer: So that you can check to make sure everything was received successfully before sending astronauts.)
  • What kinds of astronauts will be on the first crew to land on Mars? (Answer: mechanical and electrical engineers, doctors, geo-scientists, bio-scientists)
  • How will the propellant be made on the surface of Mars? (Answer: Astronauts will convert the atmosphere into methane and oxygen.)

Lesson Extension Activities

For a more detailed plan of a possible manned mission to Mars, visit the following NASA site: http://nssdc.gsfc.nasa.gov/planetary/mars/mars_crew.html.

References

Burbank, Sam and Trivedi, Bijal P. "At 'Mars on Earth,' Planning a Manned Mission," National Geographic News, December 9, 2003. http://news.nationalgeographic.com/news/2003/12/1209_031209_tvmarsonearth.html
CNN: Science and Space, "Bush unveils vision for moon and beyond," January 15, 2004. http://www.cnn.com/2004/TECH/space/01/14/bush.space/
Shaw, Malcolm J. "A Crewed Mission to Mars," NASA/Goddard Space Flight Center, November, 18, 2003. http://nssdc.gsfc.nasa.gov/planetary/mars/mars_crew.html
