Lesson: Blood Pressure Basics

Contributed by: VU Bioengineering RET Program, School of Engineering, Vanderbilt University

Photo shows a person sitting in a chair having her blood pressure check by another person using a pressure cuff.
Checking blood pressure is essential in knowing the flow of blood through the heart
copyright
Copyright © U.S. Department of Health and Human Services, National Institutes of Health (NIH) http://www.nih.gov/researchmatters/august2009/08032009bloodpressure.htm

Summary

Students study how heart valves work and investigate how valves that become faulty over time can be replaced with advancements in engineering and technology. Learning about the flow of blood through the heart, students are able to fully understand how and why the heart is such a powerful organ in our bodies.

Engineering Connection

In order to design medical devices, technologies and procedures, biomedical engineers must understand how the human body functions, as well as how disease and disorders affect the body. Once they have a thorough understanding of the unit challenge (as presented in Lesson 1) on which they are working, design solutions and choose the best one that fits their specifications. Then they test and revise their designs as needed in order to generate the best possible solution. Engineers use problem-solving skills every step of the way in designing things to improve our society.

Pre-Req Knowledge

Students should know from the first lesson of this unit, Heart to Heart, how blood flows through the heart, that it leaves the heart under pressure, and that the heart contracts to move this blood through the circulatory system.

Learning Objectives

After this lesson, students should be able to:

  • Describe what blood pressure is and how high blood pressure can impact the cardiovascular system.
  • Explain how heart valves work, as well as how they are related to blood pressure.
  • Explain how the engineering design process is used to design, build, test, redesign and retest in order to develop a solution to a problem.

More Curriculum Like This

Heart to Heart

Students learn about the form and function of the human heart through lecture, research and dissection. They brainstorm ideas that pertain to various heart conditions and organize these ideas into categories that help them research possible solutions.

High School Lesson
The Heart of the Matter

This lesson describes how the circulatory system works, including the heart, blood vessels and blood. Students learn about the chambers and valves of the heart, the difference between veins and arteries, and the different components of blood.

Elementary Lesson
Put Your Heart into Engineering

Students learn all about the body's essential mighty organ, the heart, as well as the powerful blood vascular system. This includes information on the many different sizes and pervasiveness of capillaries, veins and arteries, and how they affect blood flow through the system. Then students focus on ...

Middle School Lesson
Engineering the Heart: Heart Valves

Students learn how healthy human heart valves function and the different diseases that can affect heart valves. They also learn about devices and procedures that biomedical engineers have designed to help people with damaged or diseased heart valves.

Educational Standards

Each TeachEngineering lesson or activity is correlated to one or more K-12 science, technology, engineering or math (STEM) educational standards.

All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN), a project of D2L (www.achievementstandards.org).

In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics; within type by subtype, then by grade, etc.

  • Technological innovation often results when ideas, knowledge, or skills are shared within a technology, among technologies, or across other fields. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • The design process includes defining a problem, brainstorming, researching and generating ideas, identifying criteria and specifying constraints, exploring possibilities, selecting an approach, developing a design proposal, making a model or prototype, testing and evaluating the design using specifications, refining the design, creating or making it, and communicating processes and results. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Describe the dynamic interplay among science, technology, and engineering within living, earth-space, and physical systems. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Explore the anatomy of the heart and describe the pathway of blood through this organ. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
  • Describe the biochemical and physiological events associated with heart contraction, blood pressure, and blood clotting. (Grades 9 - 12) Details... View more aligned curriculum... Do you agree with this alignment?
Suggest an alignment not listed above

Introduction/Motivation

In our previous activity (What's with All the Pressure?), we practiced one way to monitor the pressure exerted on the arteries leading away from the heart by taking blood pressure. We did this using a very simple-looking, yet vitally intricate, device called a sphygmomanometer—also called a blood pressure cuff, or a blood pressure monitor. We also left many questions unanswered, because we did not discuss exactly what we were measuring, what the measurements mean, as well as how blood pressure is related to heart valves and our overall cardiovascular health. Today we will go over information that should answer many of these questions, and we will conduct research to answer any remaining questions.

After researching and learning about the heart anatomy and blood flow through the body, you will investigate possible solutions to the Challenge Question, which is a problem faced by many people. In the associated activity, you will design, build and test a model heart valve to replace the defective one in our hypothetical "patient." If your first design does not perform as needed, you will redesign and rebuild your model. Once complete and tested, you must inform the world of your innovative design by creating an informational pamphlet explaining the functionality, effectiveness and benefits of your model.

First though, let's research what we need to know about designing an effective heart valve and what that has to do with our blood pressure that we measured in the last activity.

Lesson Background and Concepts for Teachers

Lecture Information – Blood Pressure Basics

Present the Blood Pressure Basics Presentation to the class using the suggested script below:

Slide 1: Title: Blood Pressure Basics

Slide 2: Blood pressure is a useful diagnostic tool to assess health. Each time the heart pumps, blood is pushed into the arterial system with force. Blood pressure is the pressure that your blood exerts against your arteries as it is pumped through your body by the heart. The pressure in the arteries increases when the heart beats and decreases while it is resting. Since many heart diseases can be diagnosed through blood pressure, it is fortunate that it is easy and non-invasive to measure.

Slide 3: To measure blood pressure, two tools are used. One is a sphygmomanometer (blood pressure cuff) that fits over a person's arm and is inflated using an attached bulb. The purpose of the cuff is to temporarily stop blood flow. It also has a dial that measures pressure in the cuff. A valve lets air out of the cuff.

Slide 4: A stethoscope is the other tool used to measure blood pressure. It is an iconic medical tool used to amplify a patient's heartbeat as heard from the heart directly or as the pulse from an artery. When used with a blood pressure cuff, you can hear the blood flowing through the brachial artery (in the arm) in order to measure blood pressure.

Slide 5: To measure blood pressure, make sure the patient is seated comfortably with his/her arm supported at heart level. Wrap the blood pressure cuff around the patient's upper arm, about one inch above the elbow. Place the stethoscope just above the crease of the elbow. Quickly pump up the cuff to around 200 mmHg. While listening with the stethoscope, slowly open the valve to let the pressure fall. When you first hear the blood flow, that number is the systolic pressure. When you stop hearing the blood flow, that number is the diastolic pressure.

Slide 6: Blood pressure is measured in mmHg (millimeters of mercury) and given as a fraction:

systolic pressure / diastolic pressure

The systolic pressure measures the force generated on the arterial walls by the contraction of the ventricles (left ventricle is what is actually being measured). Diastolic pressure measures the time after the ventricles contract and the chambers of the heart are refilling with blood. For most adults, systolic pressure is considered normal when measured below 120, with 120-139 being considered pre-hypertensive and above 140 being considered hypertensive. A diastolic pressure of less than 80 is considered healthy.

Slide 7: Hypertension means abnormally high blood pressure. This includes a systolic pressure greater than 140 and a diastolic pressure of 90 or greater. Usually no symptoms are involved with hypertension, although it can be indicative of other health problems. Hypotension means abnormally low blood pressure. No specific blood pressure values are considered to be "low," but symptoms such as dizziness, blurred vision, nausea and fatigue may signify that a person's blood pressure is too low.

Slide 8: If this force is excessively high, especially for a long period of time, it can lead to health issues. High pressure puts stress on the arteries and increases the chances of an aneurysm forming or rupturing, and increases the chances that a clot or piece of plaque can be pushed into a smaller blood vessel (like a coronary artery) and cause a cerebrovascular accident (stroke) or myocardial infarction (heart attack). Hypertension can also lead to heart valve disease (which we will focus on solving in the upcoming activity). Inadequate exercise, poor diet and smoking can further compound the condition.

Biomedical engineers use the information provided by blood pressure measurements to help determine the forces that are exerted on the walls of arteries, as well as on the valves within and outside of the heart. Understanding these pressures provides a better picture of what is happening on the tissue level in the body, and a better understanding of why some valves become diseased over time.

Lecture Information – Heart Valves

(Note: Students will conduct their own research on artificial heart valves in the upcoming activity, so this information covers biological heart valves.) Human hearts have four valves: mitral valve, tricuspid valve, pulmonary valve and aortic valve. When blood enters or exits one of the four heart chambers, it always does so through a heart valve. The heart valves are one-way valves, meaning they only allow blood to travel in one direction. They open and close with the timing of the heart contractions, forcing blood to move along a given path.

Two main types of heart valve disease are identified. One type is valve stenosis, in which a heart valve can become stiff and calcified, or its leaflets may fuse together. When this happens, the valve will not fully open. The other type of heart valve disease is valve prolapse, in which a valve does not close properly. This could allow blood to leak backwards in the wrong direction through the heart valve. This regurgitation, or leaking, can become worse over time, causing the heart to work harder and harder to compensate for the leaking valve, and less blood may be pumped through the body. These conditions can eventually lead to symptoms such as shortness of breath, dizziness, heart palpitations, swelling of the ankles, feet or abdomen, weight gain and potentially fatal heart failure.

Heart valve disease is most commonly caused by one of the following: congenital valve disease (valves may be the wrong size, have malformed or incorrectly attached leaflets, or the tricuspid valve may be missing a leaflet), rheumatic fever, endocarditis (when bacteria enters the bloodstream and attacks the heart valves), coronary artery disease or a heart attack, cardiomyopathy, syphilis and high blood pressure. Other causes include aortic aneurysms, connective tissue diseases, tumors, some types of drugs and radiation.

(Note: Emphasize the connection between high blood pressure and heart valve disease in order to make a smooth transition from this lesson to its associated activity, Model Heart Valves.)

Lecture Information – Engineering Design Process

For the associated activity, it is important that students are well versed in the steps of the engineering process and understand the reason for each step in the process. See an overview of the engineering design process and an explanation of each step at https://www.teachengineering.org/engrdesignprocess.php.

Legacy Cycle Information

As an engineer, you find yourself in the Research and Revise phase of the legacy cycle, where you specifically explore different topics that may have some bearing on the Grand Challenge presented in Lesson 1. Since blood pressure is such an important component to heart and arterial health, it is beneficial for students to fully understand the principles behind what it is and how it is measured. This information eventually leads into heart valve issues, and ties into the Test Your Mettle phase of the legacy cycle.

(Note: While working on the subsequent activity, Model Heart Valves, students are in the Test Your Mettle phase of the legacy cycle. They may go through multiple design iterations until they come up with a model that functions when tested. Once their design has been tested, teams are expected to create an informational pamphlet advertising the design and testing of their models so that they can Go Public.)

Vocabulary/Definitions

diastolic: The period when heart is in relaxation and dilation; the bottom number of a blood pressure reading.

sphygmomanometer: A tool used to measure blood pressure (blood pressure cuff).

stethoscope: A tool used to listen to heart rate and pulse.

systolic: The period when the heart is contracting; the top number of a blood pressure reading.

Associated Activities

  • Model Heart Valves - Student teams follow the engineering design process to design, build, test and redesign a functioning model heart valve. Each group also creates a brochure explaining how its heart valve functions. Teams present their designs to the teacher and class, showing a demonstration of their model heart valve, explaining their brochure, and describing how their design could be a solution to this unit's Grand Challenge question.

Lesson Closure

Congratulations! You have been presented with a problem that affects your grandmother, and learned how to research information that is vital to understanding this problem.

Next, you will design a solution to help her out, which means you have gone through a complete cycle of the engineering design process. You are well on your way to becoming a biomedical engineer.

Attachments

Assessment

Pre-Lesson Assessment

Building Motivation: From their memories of the previous activity, What's with All the Pressure?, have students write the procedure for taking blood pressure. Ask them to also write any questions they have about taking blood pressure, what blood pressure really means, and what it tells us about our health. Have each student write one question on the board. Save these questions for use during the lesson smmary assessment.

Lesson Summary Assessment

Working Out the Details: Review the questions students wrote on the board at the start of the class. Ask each question to the class, and call on students to answer the questions based on information they learned in the lesson. If any questions have not been answered, but could be answered with additional research, assign students to answer those questions through research.

References

Heart Valve Disease. WebMD, LLC. Accessed November 6, 2012. http://www.webmd.com/heart-disease/guide/heart-valve-disease

Horenstein, MN. Design Concepts for Engineers, 4th edition. New York, NY: Prentice Hall, 2010.

Shier, D., Butler, J. and Lewis, R. Hole's Human Anatomy & Physiology, Eleventh Edition. New York, NY: McGraw Hill Higher Education, 2007.
