Lesson: Blow-and-Go Parachute

Quick Look

Grade Level: 8 (7-9)

Time Required: 45 minutes

Lesson Dependency: None

Subject Areas: Physical Science, Physics

A military skydiver at the AirExpo 2007 air show near Toulouse, France.
Drag slows down a skydiver's descent.
copyright
Copyright © Wikimedia Commons http://commons.wikimedia.org/wiki/File:Skydiver_-_AirExpo_Muret_2007_0240_2007-05-12.jpg

Summary

Students make a skydiver and parachute contraption to demonstrate how drag caused by air resistance slows the descent of skydivers as they travel back to Earth. Gravity pulls the skydiver toward the Earth, while the air trapped by the parachute provides an upward resisting force (drag) on the skydiver.
This engineering curriculum aligns to Next Generation Science Standards (NGSS).

Engineering Connection

To design safe recreation and transportation vehicles, engineers take into account all forces acting on the object. Sometimes they use the drag force to slow down or control a moving object, for example, in designing a parachute, vehicle brakes or paper moving through a copy machine. Engineers modify their designs to make the forces of thrust, lift, weight and drag smaller or larger, which changes how the object behaves when moving through air or water.

Learning Objectives

A drawing on the left shows a student launching the parachute flier by blowing on a straw under the paper cone. The second drawing shows four examples of falling parachutes, open and slowing the fall of each cone.
Launching the parachutes; how they fall.
copyright
Copyright © Hauser, Jill Frankel. Gizmos and Gadgets: Creating Science Contraptions that Work (and Knowing Why). Charlotte, VT: Williamson Publishing, 1999.
After this activity, students should be able to:

  • Understand which forces act on the skydiver as s/he is going up in the air and is coming back down to the ground.
  • Experimentally identify which geometric shapes most successfully reduce drag
  • Collect data from the experiment and graph the results
  • Understand why engineers need to identify how different forces interact with each other

Educational Standards

Each TeachEngineering lesson or activity is correlated to one or more K-12 science, technology, engineering or math (STEM) educational standards.

All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN), a project of D2L (www.achievementstandards.org).

In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics; within type by subtype, then by grade, etc.

NGSS Performance Expectation

MS-PS2-2. Plan an investigation to provide evidence that the change in an object's motion depends on the sum of the forces on the object and the mass of the object. (Grades 6 - 8)

Do you agree with this alignment?

Click to view other curriculum aligned to this Performance Expectation
This lesson focuses on the following Three Dimensional Learning aspects of NGSS:
Science & Engineering Practices Disciplinary Core Ideas Crosscutting Concepts
Plan an investigation individually and collaboratively, and in the design: identify independent and dependent variables and controls, what tools are needed to do the gathering, how measurements will be recorded, and how many data are needed to support a claim.

Alignment agreement:

Science knowledge is based upon logical and conceptual connections between evidence and explanations.

Alignment agreement:

The motion of an object is determined by the sum of the forces acting on it; if the total force on the object is not zero, its motion will change. The greater the mass of the object, the greater the force needed to achieve the same change in motion. For any given object, a larger force causes a larger change in motion.

Alignment agreement:

All positions of objects and the directions of forces and motions must be described in an arbitrarily chosen reference frame and arbitrarily chosen units of size. In order to share information with other people, these choices must also be shared.

Alignment agreement:

Explanations of stability and change in natural or designed systems can be constructed by examining the changes over time and forces at different scales.

Alignment agreement:

  • Knowledge gained from other fields of study has a direct effect on the development of technological products and systems. (Grades 6 - 8) More Details

    View aligned curriculum

    Do you agree with this alignment?

  • Predict and evaluate the movement of an object by examining the forces applied to it (Grade 8) More Details

    View aligned curriculum

    Do you agree with this alignment?

Suggest an alignment not listed above

Worksheets and Attachments

Visit [www.teachengineering.org/lessons/view/cub_mechanics_lesson01_activity2] to print or download.

More Curriculum Like This

Destination Outer Space

Students acquire a basic understanding of the science and engineering of space travel as well as a brief history of space exploration. They learn about the scientists and engineers who made space travel possible and briefly examine some famous space missions.

preview of 'Destination Outer Space' Lesson
Elementary Lesson
Heavy Helicopters

Students learn about weight and drag forces by making paper helicopters and measuring how adding more weight affects the time it takes for the helicopters to fall to the ground.

preview of 'Heavy Helicopters' Activity
Middle School Activity

Introduction/Motivation

Forces are invisible interactions that push and pull on things all the time. Even when you're sitting still in a chair, there are forces pushing and pulling on you. For example, the force of gravity pulls you down into the chair, and the force of air pressure helps you breathe. This activity is an investigation of forces — how forces interact, and what we can do to make forces larger and smaller. We'll use air blown through a straw to create forces called thrust and lift. Thrust and lift push our parachute up into the air, but at the same time, a force called weight is pulling the parachute down. Eventually, the parachute stops going up, and starts falling downward. Then the parachute opens up, and a force called drag slows the fall. While you're making your parachute, think about ways we can make the forces of thrust, lift, weight and drag smaller or larger. How will the interactions of these forces change the flight of the parachute?

Assessment

Pre-Activity Assessment

Discussion Question: Solicit, integrate and summarize student responses.

  • Has anyone ever seen a skydiver? How does skydiving work? (Answer: When a parachute opens up, it slows the diver down. This is an illustration of drag force.)

Activity Embedded Assessment

Worksheet: Have the students complete the activity worksheet; review their answers to gauge their mastery of the subject.

Pairs Check: After students finish working individually on worksheets, have them compare answers with a peer, giving all students time to finish the worksheet.

Post-Activity Assessment

Worksheet Discussion: Review and discuss the worksheet answers with the entire class. Use the answers to gauge students' mastery of the subject.

Lesson Extension Activities

Have the students make different-shaped skydivers and ask them how it affects the flight. (The less aerodynamically shaped the skydiver, the more drag is exerted on the skydiver in flight, decreasing the duration and height of flight).

References

Hauser, Jill Frankel. Gizmos and Gadgets: Creating Science Contraptions that Work (and Knowing Why). Charlotte, VT: Williamson Publishing, 1999.
