Hands-on Activity Exploring Bone Mineral Density, X-Rays and Biomedical Imaging

Quick Look

Grade Level: 11 (9-12)

Time Required: 45 minutes

Expendable Cost/Group: US $0.00

This activity requires computers; group size depends on the number of computers available.

Group Size: 1

Activity Dependency:

Subject Areas: Algebra

Two black and white x-ray images. A dual-energy x-ray absorptiometry (DEXA) assessment of bone mineral density of the femoral neck (A) and the lumbar spine (B): T scores of - 4.2 and - 4.3 were found at the hip (A) and lumbar spine (B), respectively in a 53 year-old male patient affected with Fabry disease.
A dual-energy x-ray absorptiometry (DEXA) assessing bone mineral density.
copyright
Copyright © 2010 Caroline Lebreton and Raymond Poincaré Chu, Wikimedia Commons http://commons.wikimedia.org/wiki/File:Morbus_Fabry_DXA_01.jpg

Summary

Student teams explore two websites to gather information on bone mineral density and how it is measured. They also learn about x-rays in general, how they work and their different uses, along with other imaging modalities. They answer guiding questions as they explore the websites and take a short quiz afterwards to test the knowledge they gained while reading the articles.

Engineering Connection

The topics of bone mineral density and x-rays are both important to biomedical engineers and are at the forefront of many areas of current research. In this initial gathering of information stage, students begin to build their knowledge base in order to come closer to answering the unit challenge question. Having a good background on how a system works is necessary to make critical decisions on its products, which in this case is an x-ray image.

Learning Objectives

After this activity, students should be able to:

  • Explain bone mineral density, its uses and tests.
  • Explain how an x-ray works.

Educational Standards

Each TeachEngineering lesson or activity is correlated to one or more K-12 science, technology, engineering or math (STEM) educational standards.

All 100,000+ K-12 STEM standards covered in TeachEngineering are collected, maintained and packaged by the Achievement Standards Network (ASN), a project of D2L (www.achievementstandards.org).

In the ASN, standards are hierarchically structured: first by source; e.g., by state; within source by type; e.g., science or mathematics; within type by subtype, then by grade, etc.

  • Apply a product, system, or process developed for one setting to another setting. (Grades 6 - 8) More Details

    View aligned curriculum

    Do you agree with this alignment?

  • Telemedicine reflects the convergence of technological advances in a number of fields, including medicine, telecommunications, virtual presence, computer engineering, informatics, artificial intelligence, robotics, materials science, and perceptual psychology. (Grades 9 - 12) More Details

    View aligned curriculum

    Do you agree with this alignment?

Suggest an alignment not listed above

Materials List

Each group needs:

  • Copy of question sheet.
  • Access to computer or printed copy of both articles.

Worksheets and Attachments

Visit [www.teachengineering.org/activities/view/van_bmd_activity1] to print or download.

Introduction/Motivation

Now that we have brainstormed a little about the challenge question, you have told me that we all need to learn more about bone mineral density and how it is measured with x-rays or otherwise. So today you are going to read a few articles and answer some questions as you go to learn more about BMD and x-rays. You might need to finish as homework. Tomorrow we will have a short quiz covering the material from the articles and from your questions you will answer.

Procedure

Before the Activity

  • Make copies of the question sheet, one per student.
  • Bookmark the websites on the computers the students will use, or make paper copies of the articles to hand out to each student.

With the Students

Ask students to navigate through the website https://www.webmd.com/osteoporosis/guide/bone-mineral-density#1 to gather information regarding what BMD is and why it is important. Using the website https://science.howstuffworks.com/x-ray.htm, direct students through a brief overview of the history and mechanics of x-rays. Be sure to point out to students the other uses of x-rays. Students should answer a series of questions as they are reading. Ask the students to turn in these questions and take a short quiz over what they have read.

Vocabulary/Definitions

attenuation: The reduction in intensity of an x-ray beam as it passes through a material.

attenuation coefficient: The measure of the reduction of the intensity of an x-ray beam that depends on the material of the object and the intensity of the x-ray beam.

BMD: Acronym for bone mineral density. The density of minerals (such as calcium) in bones.

dual-energy x-ray absortiometry: A method used to calculate bone mineral density that relies on two different X-ray beams passing through an object so that the materials inside the object can be distinguished (such as bone and soft tissue). Abbreviated as DEXA or DXA.

osteopenia: The natural thinning of bones over time.

Assessment

Post-Activity Assessment: Administer the BMD Reading Quiz. Review students' answers to gauge their depth of comprehension.

Activity Extensions

After students have completed the article worksheet, ask them again for their thoughts on the challenge question. Ask if they have any ideas to add now that they have done some research.
